RKBV1O

1" Double Union PVC Ball Valve Slip/Weld with Orange Handle

Features:

• Quarter-turn handle operated ball valve
• TPE seals with O-ring gives cushioning effect that ensures leakage free and low fixed torque
• Union nut load does not transfer onto ball
• Chemical and corrosion resistant, color UV stabilized

Material:

• Body: PVC

RKBV15O

1-1/2" Double Union PVC Ball Valve Slip/Weld with Orange Handle

Features:

• Quarter-turn handle operated ball valve
• TPE seals with O-ring gives cushioning effect that ensures leakage free and low fixed torque
• Union nut load does not transfer onto ball
• Chemical and corrosion resistant, color UV stabilized

Material:

• Body: PVC

RKBV2O

2" Double Union PVC Ball Valve Slip/Weld Orange Handle

Features:

• Quarter-turn handle operated ball valve
• TPE seals with O-ring gives cushioning effect that ensures leakage free and low fixed torque
• Union nut load does not transfer onto ball
• Chemical and corrosion resistant, color UV stabilized

Material:

• Body: PVC

RKBV3O

3" Double Union PVC Ball Valve Slip/Weld with Orange Handle

Features:

• Quarter-turn handle operated ball valve
• TPE seals with O-ring gives cushioning effect that ensures leakage free and low fixed torque
• Union nut load does not transfer onto ball
• Chemical and corrosion resistant, color UV stabilized

Material:

• Body: PVC

RKBV3OF

3" Double Union PVC Ball Valve Flanged with Orange Handle

Features:

• AS 2129 Flange Specs
• Quarter-turn handle operated ball valve
• TPE seals with O-ring gives cushioning effect that ensures leakage free and low fixed torque
• Union nut load does not transfer onto ball
• Chemical and corrosion resistant, color UV stabilized
• Built-in spanner wrench on handle for valve dissembly/assembly
• True union with flanged end design for easier installation or repair, without expanding the pipe system

Material:

• Body: PVC

RK1BV34O

3/4" Single Union PVC Ball Valve Slip/Weld

Features:

• Quarter-turn handle operated ball valve
• TPE seals with O-ring gives cushioning effect that ensures leakage free and low fixed torque
• Union nut load does not transfer onto ball
• Chemical and corrosion resistant, color UV stabilized

Material:

• Body: PVC

RK1BV34OT

3/4" Single Union PVC Ball Valve FNPT

Features:

• Quarter-turn handle operated ball valve
• TPE seals with O-ring gives cushioning effect that ensures leakage free and low fixed torque
• Union nut load does not transfer onto ball
• Chemical and corrosion resistant, color UV stabilized

Material:

• Body: PVC

RK1BV1O

1" Double Union PVC Ball Valve Slip/Weld with Orange Handle

Features:

• Quarter-turn handle operated ball valve
• TPE seals with O-ring gives cushioning effect that ensures leakage free and low fixed torque
• Union nut load does not transfer onto ball
• Chemical and corrosion resistant, color UV stabilized

Material:

• Body: PVC

RK1BV1OT

1" Single Union PVC Ball Valve FNPT Orange Handle

Features:

• Quarter-turn handle operated ball valve
• TPE seals with O-ring gives cushioning effect that ensures leakage free and low fixed torque
• Union nut load does not transfer onto ball
• Chemical and corrosion resistant, color UV stabilized

Material:

• Body: PVC

RK1BV15OT

1-1/2" Single Union PVC Ball Valve FNPT

Features:

• Quarter-turn handle operated ball valve
• TPE seals with O-ring gives cushioning effect that ensures leakage free and low fixed torque
• Union nut load does not transfer onto ball
• Chemical and corrosion resistant, color UV stabilized

Material:

• Body: PVC

RK1BV2O

2" Single Union PVC Ball Valve Slip/Weld Orange Handle

Features:

• Quarter-turn handle operated ball valve
• TPE seals with O-ring gives cushioning effect that ensures leakage free and low fixed torque
• User friendly design allows smooth operation of handle
• Union nut load does not transfer onto ball
• Chemical and corrosion resistant, color UV stabilized

Material:

• Body: PVC

RK1BV2OT

2" Single Union PVC Ball Valve Threaded FNPT Orange Handle

Features:

• Quarter-turn handle operated ball valve
• TPE seals with O-ring gives cushioning effect that ensures leakage free and low fixed torque
• User friendly design allows smooth operation of handle
• Union nut load does not transfer onto ball
• Chemical and corrosion resistant, color UV stabilized

Material:

• Body: PVC

RK1BV3O

3" Single Union PVC Ball Valve Slip/Weld with Orange Handle

Features:

• Quarter-turn handle operated ball valve
• TPE seals with O-ring gives cushioning effect that ensures leakage free and low fixed torque
• Union nut load does not transfer onto ball
• Chemical and corrosion resistant, color UV stabilized

Material:

• Body: PVC

RK1BV3OT

3" Single Union PVC Ball Valve FNPT

Features:

• Quarter-turn handle operated ball valve
• TPE seals with O-ring gives cushioning effect that ensures leakage free and low fixed torque
• Union nut load does not transfer onto ball
• Chemical and corrosion resistant, color UV stabilized

Material:

• Body: PVC

RK1BV4O

4" Single Union PVC Ball Valve Slip/Weld "

RKBB1

1" Brass Ball Valve

• Product contains brass which does not meet federal and state requirements for drinking water.

Material:

• Body: Brass
• Ball: Iron
• Stem: Iron
• Seal: PTFE
• Handle: Iron

" "

RKBB15

1-1/2" Brass Ball Valve

• Product contains brass which does not meet federal and state requirements for drinking water.

Material:

• Body: Brass
• Ball: Iron
• Stem: Iron
• Seal: PTFE
• Handle: Iron

" "

RKBB2

2" Brass Ball Valve

• Product contains brass which does not meet federal and state requirements for drinking water.

Material:

• Body: Brass
• Ball: Iron
• Stem: Iron
• Seal: PTFE
• Handle: Iron

" "

RKBB3

3" Brass Ball Valve

• Product contains brass which does not meet federal and state requirements for drinking water.

Material:

• Body: Brass
• Ball: Iron
• Stem: Iron
• Seal: PTFE
• Handle: Iron

" "

RKBB4

4" Brass Ball Valve

• Product contains brass which does not meet federal and state requirements for drinking water.

Material:

• Body: Brass
• Ball: Iron
• Stem: Iron
• Seal: PTFE
• Handle: Iron

" "

VK-BV-303F

3" Cast Iron Ball Valve, Flanged, SS304 Ball

Features:

• Fusion-Bonded Epoxy Coating Inside & Outside
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Bonnet: Cast Iron
• Ball: Stainless Steel SS304
• Seat & Gasket: PTFE
• Stem: Stainless Steel SS304
• Stem Packing: PTFE
• Lever: Ductile Iron
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	d	L	D	C	R	b	N-h	f	H	W	A	4-m
3"	3.1	8	7.5	6	5	0.8	4-19 (3/4")	0.1	8.8	13.8	0.8	M10
4"	3.9	9	9	7.5	6.2	0.9	8-19 (3/4")	0.1	8.8	15.8	0.9	M10
6"	5.9	15.5	11	9.5	8.5	1	8-22 (7/8")	0.1	10.8	23.6	1.1	M16

Dimensions - Millimeters

Size	d	L	D	C	R	b	N-h	f	H	W	A	4-m
3"	80	203	191	153	127	19.1	4-19 (3/4")	1.6	222	350	19	M10
4"	100	229	229	191	157	23.9	8-19 (3/4")	1.6	222	400	22	M10
6"	150	394	279	242	216	25.4	8-22 (7/8")	1.6	275	600	27	M16

" "

VK-BV-304F

4" Cast Iron Ball Valve, Flanged, SS304 Ball

Features:

• Fusion-Bonded Epoxy Coating Inside & Outside
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Bonnet: Cast Iron
• Ball: Stainless Steel SS304
• Seat & Gasket: PTFE
• Stem: Stainless Steel SS304
• Stem Packing: PTFE
• Lever: Ductile Iron
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	d	L	D	C	R	b	N-h	f	H	W	A	4-m
3"	3.1	8	7.5	6	5	0.8	4-19 (3/4")	0.1	8.8	13.8	0.8	M10
4"	3.9	9	9	7.5	6.2	0.9	8-19 (3/4")	0.1	8.8	15.8	0.9	M10
6"	5.9	15.5	11	9.5	8.5	1	8-22 (7/8")	0.1	10.8	23.6	1.1	M16

Dimensions - Millimeters

Size	d	L	D	C	R	b	N-h	f	H	W	A	4-m
3"	80	203	191	153	127	19.1	4-19 (3/4")	1.6	222	350	19	M10
4"	100	229	229	191	157	23.9	8-19 (3/4")	1.6	222	400	22	M10
6"	150	394	279	242	216	25.4	8-22 (7/8")	1.6	275	600	27	M16

" "

VK-BV-306F

6" Cast Iron Ball Valve, Flanged, SS304 Ball

Features:

• Fusion-Bonded Epoxy Coating Inside & Outside
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Bonnet: Cast Iron
• Ball: Stainless Steel SS304
• Seat & Gasket: PTFE
• Stem: Stainless Steel SS304
• Stem Packing: PTFE
• Lever: Ductile Iron
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	d	L	D	C	R	b	N-h	f	H	W	A	4-m
3"	3.1	8	7.5	6	5	0.8	4-19 (3/4")	0.1	8.8	13.8	0.8	M10
4"	3.9	9	9	7.5	6.2	0.9	8-19 (3/4")	0.1	8.8	15.8	0.9	M10
6"	5.9	15.5	11	9.5	8.5	1	8-22 (7/8")	0.1	10.8	23.6	1.1	M16

Dimensions - Millimeters

Size	d	L	D	C	R	b	N-h	f	H	W	A	4-m
3"	80	203	191	153	127	19.1	4-19 (3/4")	1.6	222	350	19	M10
4"	100	229	229	191	157	23.9	8-19 (3/4")	1.6	222	400	22	M10
6"	150	394	279	242	216	25.4	8-22 (7/8")	1.6	275	600	27	M16

" "

RKLV2B

2" PVC Butterfly Valve Wafer Style - EPDM Seat, Lever Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Excellent corrosion resistance
• Lever handle can lock in 10 positions for throttle control
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: uPVC
• Disc: uPVC
• Seat: EPDM
• Stem: Carbon Steel
• Locking Plate: ABS Plastic
• Lever: ABS Plastic with UV Protection

" "

RKLV3B

3" PVC Butterfly Valve Wafer Style - EPDM Seat, Lever Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Excellent corrosion resistance
• Lever handle can lock in 10 positions for throttle control
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: uPVC
• Disc: uPVC
• Seat: EPDM
• Stem: Carbon Steel
• Locking Plate: ABS Plastic
• Lever: ABS Plastic with UV Protection

" "

RKLV4B

4" PVC Butterfly Valve Wafer Style - EPDM Seat, Lever Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Excellent corrosion resistance
• Lever handle can lock in 10 positions for throttle control
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: uPVC
• Disc: uPVC
• Seat: EPDM
• Stem: Carbon Steel
• Locking Plate: ABS Plastic
• Lever: ABS Plastic with UV Protection

" "

RKLV6B

6" PVC Butterfly Valve Wafer Style - EPDM Seat, Lever Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Excellent corrosion resistance
• Lever handle can lock in 10 positions for throttle control
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: uPVC
• Disc: uPVC
• Seat: EPDM
• Stem: Carbon Steel
• Locking Plate: ABS Plastic
• Lever: ABS Plastic with UV Protection

" "

VK-BFP-106G

6" PVC Butterfly Valve Wafer Style - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Excellent corrosion resistance
• Gearbox operator is self-locking in any position for throttle control
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: uPVC
• Disc: uPVC
• Seat: EPDM
• Stem: Carbon Steel
• Handwheel: Painted Cast Iron

" "

VK-BFP-108G

8" PVC Butterfly Valve Wafer Style - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Excellent corrosion resistance
• Gearbox operator is self-locking in any position for throttle control
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: uPVC
• Disc: uPVC
• Seat: EPDM
• Stem: Carbon Steel
• Handwheel: Painted Cast Iron

" "

VK-BFP-110G

10" PVC Butterfly Valve Wafer Style - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Excellent corrosion resistance
• Gearbox operator is self-locking in any position for throttle control
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: uPVC
• Disc: uPVC
• Seat: EPDM
• Stem: Carbon Steel
• Handwheel: Painted Cast Iron

" "

RKLO2

2" Cast Iron Butterfly Valve Wafer - EPDM Seat, Lever Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Lever handle can lock in 10 positions for throttle control
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Locking Plate: Stainless Steel SS420
• Lever: Malleable Iron
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	a°	⌀D	⌀E	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	45°	4.8	0.7	1.6	10.1	0.5	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	45°	6	0.7	1.8	10.1	0.5	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	22.5°	7.5	0.7	2.1	10.1	0.6	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	22.5°	9.5	0.8	2.2	10.1	0.8	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	22.5°	11.8	0.8	2.4	14	0.9	0.7	4	4.9	0.4
10"	8	11.5	1.5	15°	14.3	0.9	2.6	14	1.1	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	15°	17	0.9	3.1	14	1.3	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	a°	⌀D	⌀E	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	76	162	32	45°	120.7	17.46	42	255	12.7	10	70	90	9.5
3"	95	181	32	45°	152.4	17.46	45	255	12.7	10	70	90	9.5
4"	114	200	32	22.5°	190.5	17.46	52	255	15.88	12	70	90	9.5
6"	139	225	32	22.5°	241.3	20.64	56	255	19.05	14	70	90	9.5
8"	177	260	38	22.5°	298.5	20.64	60	355	22.23	17	102	125	11.5
10"	203	292	38	15°	362	23.81	66	355	28.58	22	102	125	11.5
12"	242	337	38	15°	431.8	23.81	77	355	31.75	24	102	125	11.5

" "

RKLO3

3" Cast Iron Butterfly Valve Wafer - EPDM Seat, Lever Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Lever handle can lock in 10 positions for throttle control
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Locking Plate: Stainless Steel SS420
• Lever: Malleable Iron
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	a°	⌀D	⌀E	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	45°	4.8	0.7	1.6	10.1	0.5	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	45°	6	0.7	1.8	10.1	0.5	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	22.5°	7.5	0.7	2.1	10.1	0.6	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	22.5°	9.5	0.8	2.2	10.1	0.8	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	22.5°	11.8	0.8	2.4	14	0.9	0.7	4	4.9	0.4
10"	8	11.5	1.5	15°	14.3	0.9	2.6	14	1.1	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	15°	17	0.9	3.1	14	1.3	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	a°	⌀D	⌀E	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	76	162	32	45°	120.7	17.46	42	255	12.7	10	70	90	9.5
3"	95	181	32	45°	152.4	17.46	45	255	12.7	10	70	90	9.5
4"	114	200	32	22.5°	190.5	17.46	52	255	15.88	12	70	90	9.5
6"	139	225	32	22.5°	241.3	20.64	56	255	19.05	14	70	90	9.5
8"	177	260	38	22.5°	298.5	20.64	60	355	22.23	17	102	125	11.5
10"	203	292	38	15°	362	23.81	66	355	28.58	22	102	125	11.5
12"	242	337	38	15°	431.8	23.81	77	355	31.75	24	102	125	11.5

" "

RKLO4

4" Cast Iron Butterfly Valve Wafer - EPDM Seat, Lever Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Lever handle can lock in 10 positions for throttle control
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Locking Plate: Stainless Steel SS420
• Lever: Malleable Iron
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	a°	⌀D	⌀E	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	45°	4.8	0.7	1.6	10.1	0.5	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	45°	6	0.7	1.8	10.1	0.5	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	22.5°	7.5	0.7	2.1	10.1	0.6	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	22.5°	9.5	0.8	2.2	10.1	0.8	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	22.5°	11.8	0.8	2.4	14	0.9	0.7	4	4.9	0.4
10"	8	11.5	1.5	15°	14.3	0.9	2.6	14	1.1	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	15°	17	0.9	3.1	14	1.3	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	a°	⌀D	⌀E	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	76	162	32	45°	120.7	17.46	42	255	12.7	10	70	90	9.5
3"	95	181	32	45°	152.4	17.46	45	255	12.7	10	70	90	9.5
4"	114	200	32	22.5°	190.5	17.46	52	255	15.88	12	70	90	9.5
6"	139	225	32	22.5°	241.3	20.64	56	255	19.05	14	70	90	9.5
8"	177	260	38	22.5°	298.5	20.64	60	355	22.23	17	102	125	11.5
10"	203	292	38	15°	362	23.81	66	355	28.58	22	102	125	11.5
12"	242	337	38	15°	431.8	23.81	77	355	31.75	24	102	125	11.5

" "

RKLO6

6" Cast Iron Butterfly Valve Wafer - EPDM Seat, Lever Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Lever handle can lock in 10 positions for throttle control
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Locking Plate: Stainless Steel SS420
• Lever: Malleable Iron
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	a°	⌀D	⌀E	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	45°	4.8	0.7	1.6	10.1	0.5	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	45°	6	0.7	1.8	10.1	0.5	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	22.5°	7.5	0.7	2.1	10.1	0.6	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	22.5°	9.5	0.8	2.2	10.1	0.8	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	22.5°	11.8	0.8	2.4	14	0.9	0.7	4	4.9	0.4
10"	8	11.5	1.5	15°	14.3	0.9	2.6	14	1.1	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	15°	17	0.9	3.1	14	1.3	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	a°	⌀D	⌀E	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	76	162	32	45°	120.7	17.46	42	255	12.7	10	70	90	9.5
3"	95	181	32	45°	152.4	17.46	45	255	12.7	10	70	90	9.5
4"	114	200	32	22.5°	190.5	17.46	52	255	15.88	12	70	90	9.5
6"	139	225	32	22.5°	241.3	20.64	56	255	19.05	14	70	90	9.5
8"	177	260	38	22.5°	298.5	20.64	60	355	22.23	17	102	125	11.5
10"	203	292	38	15°	362	23.81	66	355	28.58	22	102	125	11.5
12"	242	337	38	15°	431.8	23.81	77	355	31.75	24	102	125	11.5

" "

RKLO8

8" Cast Iron Butterfly Valve Wafer - EPDM Seat, Lever Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Lever handle can lock in 10 positions for throttle control
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Locking Plate: Stainless Steel SS420
• Lever: Malleable Iron
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	a°	⌀D	⌀E	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	45°	4.8	0.7	1.6	10.1	0.5	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	45°	6	0.7	1.8	10.1	0.5	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	22.5°	7.5	0.7	2.1	10.1	0.6	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	22.5°	9.5	0.8	2.2	10.1	0.8	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	22.5°	11.8	0.8	2.4	14	0.9	0.7	4	4.9	0.4
10"	8	11.5	1.5	15°	14.3	0.9	2.6	14	1.1	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	15°	17	0.9	3.1	14	1.3	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	a°	⌀D	⌀E	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	76	162	32	45°	120.7	17.46	42	255	12.7	10	70	90	9.5
3"	95	181	32	45°	152.4	17.46	45	255	12.7	10	70	90	9.5
4"	114	200	32	22.5°	190.5	17.46	52	255	15.88	12	70	90	9.5
6"	139	225	32	22.5°	241.3	20.64	56	255	19.05	14	70	90	9.5
8"	177	260	38	22.5°	298.5	20.64	60	355	22.23	17	102	125	11.5
10"	203	292	38	15°	362	23.81	66	355	28.58	22	102	125	11.5
12"	242	337	38	15°	431.8	23.81	77	355	31.75	24	102	125	11.5

" "

RKLO10

10" Cast Iron Butterfly Valve Wafer - EPDM Seat, Lever Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Lever handle can lock in 10 positions for throttle control
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Locking Plate: Stainless Steel SS420
• Lever: Malleable Iron
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	a°	⌀D	⌀E	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	45°	4.8	0.7	1.6	10.1	0.5	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	45°	6	0.7	1.8	10.1	0.5	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	22.5°	7.5	0.7	2.1	10.1	0.6	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	22.5°	9.5	0.8	2.2	10.1	0.8	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	22.5°	11.8	0.8	2.4	14	0.9	0.7	4	4.9	0.4
10"	8	11.5	1.5	15°	14.3	0.9	2.6	14	1.1	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	15°	17	0.9	3.1	14	1.3	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	a°	⌀D	⌀E	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	76	162	32	45°	120.7	17.46	42	255	12.7	10	70	90	9.5
3"	95	181	32	45°	152.4	17.46	45	255	12.7	10	70	90	9.5
4"	114	200	32	22.5°	190.5	17.46	52	255	15.88	12	70	90	9.5
6"	139	225	32	22.5°	241.3	20.64	56	255	19.05	14	70	90	9.5
8"	177	260	38	22.5°	298.5	20.64	60	355	22.23	17	102	125	11.5
10"	203	292	38	15°	362	23.81	66	355	28.58	22	102	125	11.5
12"	242	337	38	15°	431.8	23.81	77	355	31.75	24	102	125	11.5

" "

RKG6

6" Cast Iron Butterfly Valve Wafer - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Gearbox operator is self-locking in any position for throttle control
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	a°	⌀D	⌀E	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	45°	4.8	0.7	1.8	5.3	1.1	5.5	1.6	0.5	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	45°	6	0.7	1.8	5.3	1.1	5.5	1.8	0.5	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	22.5°	7.5	0.7	1.8	5.3	1.1	5.5	2.1	0.6	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	22.5°	9.5	0.8	1.8	5.3	1.1	5.5	2.2	0.8	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	22.5°	11.8	0.8	2.4	10.8	1.6	8.3	2.4	0.9	0.7	4	4.9	0.4
10"	8	11.5	1.5	15°	14.3	0.9	2.4	10.8	1.6	8.3	2.6	1.1	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	15°	17	0.9	3.1	10.8	1.6	8.7	3.1	1.3	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	a°	⌀D	⌀E	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
2"	76	162	32	45°	121	17.5	44	135	28	139	42	12.7	10	70	90	9.5
3"	95	181	32	45°	152	17.5	44	135	28	139	45	12.7	10	70	90	9.5
4"	114	200	32	22.5°	191	17.5	44	135	28	139	52	15.88	12	70	90	9.5
6"	139	225	32	22.5°	241	20.6	44	135	28	139	56	19.05	14	70	90	9.5
8"	177	260	38	22.5°	298	20.6	62	275	40	211	60	22.23	17	102	125	11.5
10"	203	292	38	15°	362	23.8	62	275	40	211	66	28.58	22	102	125	11.5
12"	242	337	38	15°	432	23.8	78	275	40	220	77	31.75	24	102	125	11.5

" "

RKG8

8" Cast Iron Butterfly Valve Wafer - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Gearbox operator is self-locking in any position for throttle control
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	a°	⌀D	⌀E	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	45°	4.8	0.7	1.8	5.3	1.1	5.5	1.6	0.5	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	45°	6	0.7	1.8	5.3	1.1	5.5	1.8	0.5	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	22.5°	7.5	0.7	1.8	5.3	1.1	5.5	2.1	0.6	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	22.5°	9.5	0.8	1.8	5.3	1.1	5.5	2.2	0.8	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	22.5°	11.8	0.8	2.4	10.8	1.6	8.3	2.4	0.9	0.7	4	4.9	0.4
10"	8	11.5	1.5	15°	14.3	0.9	2.4	10.8	1.6	8.3	2.6	1.1	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	15°	17	0.9	3.1	10.8	1.6	8.7	3.1	1.3	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	a°	⌀D	⌀E	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
2"	76	162	32	45°	121	17.5	44	135	28	139	42	12.7	10	70	90	9.5
3"	95	181	32	45°	152	17.5	44	135	28	139	45	12.7	10	70	90	9.5
4"	114	200	32	22.5°	191	17.5	44	135	28	139	52	15.88	12	70	90	9.5
6"	139	225	32	22.5°	241	20.6	44	135	28	139	56	19.05	14	70	90	9.5
8"	177	260	38	22.5°	298	20.6	62	275	40	211	60	22.23	17	102	125	11.5
10"	203	292	38	15°	362	23.8	62	275	40	211	66	28.58	22	102	125	11.5
12"	242	337	38	15°	432	23.8	78	275	40	220	77	31.75	24	102	125	11.5

" "

RKG10

10" Cast Iron Butterfly Valve Wafer - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Gearbox operator is self-locking in any position for throttle control
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	a°	⌀D	⌀E	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	45°	4.8	0.7	1.8	5.3	1.1	5.5	1.6	0.5	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	45°	6	0.7	1.8	5.3	1.1	5.5	1.8	0.5	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	22.5°	7.5	0.7	1.8	5.3	1.1	5.5	2.1	0.6	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	22.5°	9.5	0.8	1.8	5.3	1.1	5.5	2.2	0.8	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	22.5°	11.8	0.8	2.4	10.8	1.6	8.3	2.4	0.9	0.7	4	4.9	0.4
10"	8	11.5	1.5	15°	14.3	0.9	2.4	10.8	1.6	8.3	2.6	1.1	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	15°	17	0.9	3.1	10.8	1.6	8.7	3.1	1.3	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	a°	⌀D	⌀E	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
2"	76	162	32	45°	121	17.5	44	135	28	139	42	12.7	10	70	90	9.5
3"	95	181	32	45°	152	17.5	44	135	28	139	45	12.7	10	70	90	9.5
4"	114	200	32	22.5°	191	17.5	44	135	28	139	52	15.88	12	70	90	9.5
6"	139	225	32	22.5°	241	20.6	44	135	28	139	56	19.05	14	70	90	9.5
8"	177	260	38	22.5°	298	20.6	62	275	40	211	60	22.23	17	102	125	11.5
10"	203	292	38	15°	362	23.8	62	275	40	211	66	28.58	22	102	125	11.5
12"	242	337	38	15°	432	23.8	78	275	40	220	77	31.75	24	102	125	11.5

" "

RKG12

12" Cast Iron Butterfly Valve Wafer - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Gearbox operator is self-locking in any position for throttle control
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	a°	⌀D	⌀E	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	45°	4.8	0.7	1.8	5.3	1.1	5.5	1.6	0.5	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	45°	6	0.7	1.8	5.3	1.1	5.5	1.8	0.5	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	22.5°	7.5	0.7	1.8	5.3	1.1	5.5	2.1	0.6	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	22.5°	9.5	0.8	1.8	5.3	1.1	5.5	2.2	0.8	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	22.5°	11.8	0.8	2.4	10.8	1.6	8.3	2.4	0.9	0.7	4	4.9	0.4
10"	8	11.5	1.5	15°	14.3	0.9	2.4	10.8	1.6	8.3	2.6	1.1	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	15°	17	0.9	3.1	10.8	1.6	8.7	3.1	1.3	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	a°	⌀D	⌀E	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
2"	76	162	32	45°	121	17.5	44	135	28	139	42	12.7	10	70	90	9.5
3"	95	181	32	45°	152	17.5	44	135	28	139	45	12.7	10	70	90	9.5
4"	114	200	32	22.5°	191	17.5	44	135	28	139	52	15.88	12	70	90	9.5
6"	139	225	32	22.5°	241	20.6	44	135	28	139	56	19.05	14	70	90	9.5
8"	177	260	38	22.5°	298	20.6	62	275	40	211	60	22.23	17	102	125	11.5
10"	203	292	38	15°	362	23.8	62	275	40	211	66	28.58	22	102	125	11.5
12"	242	337	38	15°	432	23.8	78	275	40	220	77	31.75	24	102	125	11.5

" "

VK-BF-202L

2" Cast Iron Butterfly Valve Lug Style - EPDM Seat, Lever Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Lever handle can lock in 10 positions for throttle control
• Lug style body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Locking Plate: Stainless Steel SS420
• Lever: Malleable Iron
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D	M	N	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	4.8	5/8"-11 UNC	4	1.6	10.1	0.5	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	6	5/8"-11 UNC	4	1.8	10.1	0.5	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	7.5	5/8"-11 UNC	8	2.1	10.1	0.6	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	9.5	3/4"-10 UNC	8	2.2	10.1	0.8	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	11.8	3/4"-10 UNC	8	2.4	14	0.9	0.7	4	4.9	0.4
10"	8	11.5	1.5	14.3	7/8"-9 UNC	12	2.6	14	1.1	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	17	7/8"-9 UNC	12	3.1	14	1.3	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D	M	N	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	76	162	32	120.7	5/8"-11 UNC	4	42	255	12.7	10	70	90	9.5
3"	95	181	32	152.4	5/8"-11 UNC	4	45	255	12.7	10	70	90	9.5
4"	114	200	32	190.5	5/8"-11 UNC	8	52	255	15.88	12	70	90	9.5
6"	139	225	32	241.3	3/4"-10 UNC	8	56	255	19.05	14	70	90	9.5
8"	177	260	38	298.5	3/4"-10 UNC	8	60	355	22.23	17	102	125	11.5
10"	203	292	38	362	7/8"-9 UNC	12	66	355	28.58	22	102	125	11.5
12"	242	337	38	431.8	7/8"-9 UNC	12	77	355	31.75	24	102	125	11.5

" "

VK-BF-203L

3" Cast Iron Butterfly Valve Lug Style - EPDM Seat, Lever Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Lever handle can lock in 10 positions for throttle control
• Lug style body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Locking Plate: Stainless Steel SS420
• Lever: Malleable Iron
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D	M	N	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	4.8	5/8"-11 UNC	4	1.6	10.1	0.5	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	6	5/8"-11 UNC	4	1.8	10.1	0.5	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	7.5	5/8"-11 UNC	8	2.1	10.1	0.6	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	9.5	3/4"-10 UNC	8	2.2	10.1	0.8	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	11.8	3/4"-10 UNC	8	2.4	14	0.9	0.7	4	4.9	0.4
10"	8	11.5	1.5	14.3	7/8"-9 UNC	12	2.6	14	1.1	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	17	7/8"-9 UNC	12	3.1	14	1.3	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D	M	N	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	76	162	32	120.7	5/8"-11 UNC	4	42	255	12.7	10	70	90	9.5
3"	95	181	32	152.4	5/8"-11 UNC	4	45	255	12.7	10	70	90	9.5
4"	114	200	32	190.5	5/8"-11 UNC	8	52	255	15.88	12	70	90	9.5
6"	139	225	32	241.3	3/4"-10 UNC	8	56	255	19.05	14	70	90	9.5
8"	177	260	38	298.5	3/4"-10 UNC	8	60	355	22.23	17	102	125	11.5
10"	203	292	38	362	7/8"-9 UNC	12	66	355	28.58	22	102	125	11.5
12"	242	337	38	431.8	7/8"-9 UNC	12	77	355	31.75	24	102	125	11.5

" "

VK-BF-204L

4" Cast Iron Butterfly Valve Lug Style - EPDM Seat, Lever Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Lever handle can lock in 10 positions for throttle control
• Lug style body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Locking Plate: Stainless Steel SS420
• Lever: Malleable Iron
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D	M	N	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	4.8	5/8"-11 UNC	4	1.6	10.1	0.5	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	6	5/8"-11 UNC	4	1.8	10.1	0.5	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	7.5	5/8"-11 UNC	8	2.1	10.1	0.6	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	9.5	3/4"-10 UNC	8	2.2	10.1	0.8	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	11.8	3/4"-10 UNC	8	2.4	14	0.9	0.7	4	4.9	0.4
10"	8	11.5	1.5	14.3	7/8"-9 UNC	12	2.6	14	1.1	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	17	7/8"-9 UNC	12	3.1	14	1.3	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D	M	N	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	76	162	32	120.7	5/8"-11 UNC	4	42	255	12.7	10	70	90	9.5
3"	95	181	32	152.4	5/8"-11 UNC	4	45	255	12.7	10	70	90	9.5
4"	114	200	32	190.5	5/8"-11 UNC	8	52	255	15.88	12	70	90	9.5
6"	139	225	32	241.3	3/4"-10 UNC	8	56	255	19.05	14	70	90	9.5
8"	177	260	38	298.5	3/4"-10 UNC	8	60	355	22.23	17	102	125	11.5
10"	203	292	38	362	7/8"-9 UNC	12	66	355	28.58	22	102	125	11.5
12"	242	337	38	431.8	7/8"-9 UNC	12	77	355	31.75	24	102	125	11.5

" "

VK-BF-206L

6" Cast Iron Butterfly Valve Lug Style - EPDM Seat, Lever Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Lever handle can lock in 10 positions for throttle control
• Lug style body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Locking Plate: Stainless Steel SS420
• Lever: Malleable Iron
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D	M	N	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	4.8	5/8"-11 UNC	4	1.6	10.1	0.5	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	6	5/8"-11 UNC	4	1.8	10.1	0.5	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	7.5	5/8"-11 UNC	8	2.1	10.1	0.6	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	9.5	3/4"-10 UNC	8	2.2	10.1	0.8	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	11.8	3/4"-10 UNC	8	2.4	14	0.9	0.7	4	4.9	0.4
10"	8	11.5	1.5	14.3	7/8"-9 UNC	12	2.6	14	1.1	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	17	7/8"-9 UNC	12	3.1	14	1.3	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D	M	N	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	76	162	32	120.7	5/8"-11 UNC	4	42	255	12.7	10	70	90	9.5
3"	95	181	32	152.4	5/8"-11 UNC	4	45	255	12.7	10	70	90	9.5
4"	114	200	32	190.5	5/8"-11 UNC	8	52	255	15.88	12	70	90	9.5
6"	139	225	32	241.3	3/4"-10 UNC	8	56	255	19.05	14	70	90	9.5
8"	177	260	38	298.5	3/4"-10 UNC	8	60	355	22.23	17	102	125	11.5
10"	203	292	38	362	7/8"-9 UNC	12	66	355	28.58	22	102	125	11.5
12"	242	337	38	431.8	7/8"-9 UNC	12	77	355	31.75	24	102	125	11.5

" "

VK-BF-208L

8" Cast Iron Butterfly Valve Lug Style - EPDM Seat, Lever Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Lever handle can lock in 10 positions for throttle control
• Lug style body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Locking Plate: Stainless Steel SS420
• Lever: Malleable Iron
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D	M	N	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	4.8	5/8"-11 UNC	4	1.6	10.1	0.5	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	6	5/8"-11 UNC	4	1.8	10.1	0.5	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	7.5	5/8"-11 UNC	8	2.1	10.1	0.6	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	9.5	3/4"-10 UNC	8	2.2	10.1	0.8	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	11.8	3/4"-10 UNC	8	2.4	14	0.9	0.7	4	4.9	0.4
10"	8	11.5	1.5	14.3	7/8"-9 UNC	12	2.6	14	1.1	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	17	7/8"-9 UNC	12	3.1	14	1.3	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D	M	N	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	76	162	32	120.7	5/8"-11 UNC	4	42	255	12.7	10	70	90	9.5
3"	95	181	32	152.4	5/8"-11 UNC	4	45	255	12.7	10	70	90	9.5
4"	114	200	32	190.5	5/8"-11 UNC	8	52	255	15.88	12	70	90	9.5
6"	139	225	32	241.3	3/4"-10 UNC	8	56	255	19.05	14	70	90	9.5
8"	177	260	38	298.5	3/4"-10 UNC	8	60	355	22.23	17	102	125	11.5
10"	203	292	38	362	7/8"-9 UNC	12	66	355	28.58	22	102	125	11.5
12"	242	337	38	431.8	7/8"-9 UNC	12	77	355	31.75	24	102	125	11.5

" "

VK-BF-210L

10" Cast Iron Butterfly Valve Lug Style - EPDM Seat, Lever Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Lever handle can lock in 10 positions for throttle control
• Lug style body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Locking Plate: Stainless Steel SS420
• Lever: Malleable Iron
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D	M	N	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	4.8	5/8"-11 UNC	4	1.6	10.1	0.5	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	6	5/8"-11 UNC	4	1.8	10.1	0.5	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	7.5	5/8"-11 UNC	8	2.1	10.1	0.6	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	9.5	3/4"-10 UNC	8	2.2	10.1	0.8	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	11.8	3/4"-10 UNC	8	2.4	14	0.9	0.7	4	4.9	0.4
10"	8	11.5	1.5	14.3	7/8"-9 UNC	12	2.6	14	1.1	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	17	7/8"-9 UNC	12	3.1	14	1.3	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D	M	N	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	76	162	32	120.7	5/8"-11 UNC	4	42	255	12.7	10	70	90	9.5
3"	95	181	32	152.4	5/8"-11 UNC	4	45	255	12.7	10	70	90	9.5
4"	114	200	32	190.5	5/8"-11 UNC	8	52	255	15.88	12	70	90	9.5
6"	139	225	32	241.3	3/4"-10 UNC	8	56	255	19.05	14	70	90	9.5
8"	177	260	38	298.5	3/4"-10 UNC	8	60	355	22.23	17	102	125	11.5
10"	203	292	38	362	7/8"-9 UNC	12	66	355	28.58	22	102	125	11.5
12"	242	337	38	431.8	7/8"-9 UNC	12	77	355	31.75	24	102	125	11.5

" "

VK-BF-212L

12" Cast Iron Butterfly Valve Lug Style - EPDM Seat, Lever Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Lever handle can lock in 10 positions for throttle control
• Lug style body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Locking Plate: Stainless Steel SS420
• Lever: Malleable Iron
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D	M	N	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	4.8	5/8"-11 UNC	4	1.6	10.1	0.5	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	6	5/8"-11 UNC	4	1.8	10.1	0.5	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	7.5	5/8"-11 UNC	8	2.1	10.1	0.6	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	9.5	3/4"-10 UNC	8	2.2	10.1	0.8	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	11.8	3/4"-10 UNC	8	2.4	14	0.9	0.7	4	4.9	0.4
10"	8	11.5	1.5	14.3	7/8"-9 UNC	12	2.6	14	1.1	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	17	7/8"-9 UNC	12	3.1	14	1.3	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D	M	N	L	P	⌀Q	S	⌀T	⌀U	⌀V
2"	76	162	32	120.7	5/8"-11 UNC	4	42	255	12.7	10	70	90	9.5
3"	95	181	32	152.4	5/8"-11 UNC	4	45	255	12.7	10	70	90	9.5
4"	114	200	32	190.5	5/8"-11 UNC	8	52	255	15.88	12	70	90	9.5
6"	139	225	32	241.3	3/4"-10 UNC	8	56	255	19.05	14	70	90	9.5
8"	177	260	38	298.5	3/4"-10 UNC	8	60	355	22.23	17	102	125	11.5
10"	203	292	38	362	7/8"-9 UNC	12	66	355	28.58	22	102	125	11.5
12"	242	337	38	431.8	7/8"-9 UNC	12	77	355	31.75	24	102	125	11.5

" "

VK-BF-202G

2" Cast Iron Butterfly Valve Lug Style - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Gearbox operator is self-locking in any position for throttle control
• Lug style body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D (in. mm)	M	N	E	⌀F	G	H	⌀Q	L	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	4.8	5/8"-10 UNC	0.2	1.8	5.3	1.1	5.5	0.5	1.6	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	6	5/8"-10 UNC	0.2	1.8	5.3	1.1	5.5	0.5	1.8	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	7.5	5/8"-10 UNC	0.3	1.8	5.3	1.1	5.5	0.6	2.1	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	9.5	3/4"-10 UNC	0.3	1.8	5.3	1.1	5.5	0.8	2.2	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	11.8	3/4"-10 UNC	0.3	2.4	10.8	1.6	8.3	0.9	2.4	0.7	4	4.9	0.4
10"	8	11.5	1.5	14.3	7/8"-9 UNC	0.5	2.4	10.8	1.6	8.3	1.1	2.6	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	17	7/8"-9 UNC	0.5	3.1	10.8	1.6	8.7	1.3	3.1	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D (in. mm)	M	N	E	⌀F	G	H	⌀Q	L	S	⌀T	⌀U	⌀V
2"	76	162	32	121	5/8"-10 UNC	4	44	135	28	139	12.7	42	10	70	90	9.5
3"	95	181	32	152	5/8"-10 UNC	4	44	135	28	139	12.7	45	10	70	90	9.5
4"	114	200	32	191	5/8"-10 UNC	8	44	135	28	139	15.88	52	12	70	90	9.5
6"	139	225	32	241	3/4"-10 UNC	8	44	135	28	139	19.05	56	14	70	90	9.5
8"	177	260	38	298	3/4"-10 UNC	8	62	275	40	211	22.23	60	17	102	125	11.5
10"	203	292	38	362	7/8"-9 UNC	12	62	275	40	211	28.58	66	22	102	125	11.5
12"	242	337	38	432	7/8"-9 UNC	12	78	275	40	220	31.75	77	24	102	125	11.5

" "

VK-BF-203G

3" Cast iron Buttterfly Valve Lug Style - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Gearbox operator is self-locking in any position for throttle control
• Lug style body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D (in. mm)	M	N	E	⌀F	G	H	⌀Q	L	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	4.8	5/8"-10 UNC	0.2	1.8	5.3	1.1	5.5	0.5	1.6	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	6	5/8"-10 UNC	0.2	1.8	5.3	1.1	5.5	0.5	1.8	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	7.5	5/8"-10 UNC	0.3	1.8	5.3	1.1	5.5	0.6	2.1	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	9.5	3/4"-10 UNC	0.3	1.8	5.3	1.1	5.5	0.8	2.2	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	11.8	3/4"-10 UNC	0.3	2.4	10.8	1.6	8.3	0.9	2.4	0.7	4	4.9	0.4
10"	8	11.5	1.5	14.3	7/8"-9 UNC	0.5	2.4	10.8	1.6	8.3	1.1	2.6	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	17	7/8"-9 UNC	0.5	3.1	10.8	1.6	8.7	1.3	3.1	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D (in. mm)	M	N	E	⌀F	G	H	⌀Q	L	S	⌀T	⌀U	⌀V
2"	76	162	32	121	5/8"-10 UNC	4	44	135	28	139	12.7	42	10	70	90	9.5
3"	95	181	32	152	5/8"-10 UNC	4	44	135	28	139	12.7	45	10	70	90	9.5
4"	114	200	32	191	5/8"-10 UNC	8	44	135	28	139	15.88	52	12	70	90	9.5
6"	139	225	32	241	3/4"-10 UNC	8	44	135	28	139	19.05	56	14	70	90	9.5
8"	177	260	38	298	3/4"-10 UNC	8	62	275	40	211	22.23	60	17	102	125	11.5
10"	203	292	38	362	7/8"-9 UNC	12	62	275	40	211	28.58	66	22	102	125	11.5
12"	242	337	38	432	7/8"-9 UNC	12	78	275	40	220	31.75	77	24	102	125	11.5

" "

VK-BF-204G

4" Cast Iron Butterfly Valve Lug Style - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Gearbox operator is self-locking in any position for throttle control
• Lug style body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D (in. mm)	M	N	E	⌀F	G	H	⌀Q	L	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	4.8	5/8"-10 UNC	0.2	1.8	5.3	1.1	5.5	0.5	1.6	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	6	5/8"-10 UNC	0.2	1.8	5.3	1.1	5.5	0.5	1.8	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	7.5	5/8"-10 UNC	0.3	1.8	5.3	1.1	5.5	0.6	2.1	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	9.5	3/4"-10 UNC	0.3	1.8	5.3	1.1	5.5	0.8	2.2	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	11.8	3/4"-10 UNC	0.3	2.4	10.8	1.6	8.3	0.9	2.4	0.7	4	4.9	0.4
10"	8	11.5	1.5	14.3	7/8"-9 UNC	0.5	2.4	10.8	1.6	8.3	1.1	2.6	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	17	7/8"-9 UNC	0.5	3.1	10.8	1.6	8.7	1.3	3.1	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D (in. mm)	M	N	E	⌀F	G	H	⌀Q	L	S	⌀T	⌀U	⌀V
2"	76	162	32	121	5/8"-10 UNC	4	44	135	28	139	12.7	42	10	70	90	9.5
3"	95	181	32	152	5/8"-10 UNC	4	44	135	28	139	12.7	45	10	70	90	9.5
4"	114	200	32	191	5/8"-10 UNC	8	44	135	28	139	15.88	52	12	70	90	9.5
6"	139	225	32	241	3/4"-10 UNC	8	44	135	28	139	19.05	56	14	70	90	9.5
8"	177	260	38	298	3/4"-10 UNC	8	62	275	40	211	22.23	60	17	102	125	11.5
10"	203	292	38	362	7/8"-9 UNC	12	62	275	40	211	28.58	66	22	102	125	11.5
12"	242	337	38	432	7/8"-9 UNC	12	78	275	40	220	31.75	77	24	102	125	11.5

" "

VK-BF-206G

6" Cast Iron Butterfly Valve Lug Style - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Gearbox operator is self-locking in any position for throttle control
• Lug style body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D (in. mm)	M	N	E	⌀F	G	H	⌀Q	L	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	4.8	5/8"-10 UNC	0.2	1.8	5.3	1.1	5.5	0.5	1.6	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	6	5/8"-10 UNC	0.2	1.8	5.3	1.1	5.5	0.5	1.8	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	7.5	5/8"-10 UNC	0.3	1.8	5.3	1.1	5.5	0.6	2.1	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	9.5	3/4"-10 UNC	0.3	1.8	5.3	1.1	5.5	0.8	2.2	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	11.8	3/4"-10 UNC	0.3	2.4	10.8	1.6	8.3	0.9	2.4	0.7	4	4.9	0.4
10"	8	11.5	1.5	14.3	7/8"-9 UNC	0.5	2.4	10.8	1.6	8.3	1.1	2.6	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	17	7/8"-9 UNC	0.5	3.1	10.8	1.6	8.7	1.3	3.1	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D (in. mm)	M	N	E	⌀F	G	H	⌀Q	L	S	⌀T	⌀U	⌀V
2"	76	162	32	121	5/8"-10 UNC	4	44	135	28	139	12.7	42	10	70	90	9.5
3"	95	181	32	152	5/8"-10 UNC	4	44	135	28	139	12.7	45	10	70	90	9.5
4"	114	200	32	191	5/8"-10 UNC	8	44	135	28	139	15.88	52	12	70	90	9.5
6"	139	225	32	241	3/4"-10 UNC	8	44	135	28	139	19.05	56	14	70	90	9.5
8"	177	260	38	298	3/4"-10 UNC	8	62	275	40	211	22.23	60	17	102	125	11.5
10"	203	292	38	362	7/8"-9 UNC	12	62	275	40	211	28.58	66	22	102	125	11.5
12"	242	337	38	432	7/8"-9 UNC	12	78	275	40	220	31.75	77	24	102	125	11.5

" "

VK-BF-208G

8" Cast Iron Butterfly Valve Lug Style - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Gearbox operator is self-locking in any position for throttle control
• Lug style body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D (in. mm)	M	N	E	⌀F	G	H	⌀Q	L	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	4.8	5/8"-10 UNC	0.2	1.8	5.3	1.1	5.5	0.5	1.6	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	6	5/8"-10 UNC	0.2	1.8	5.3	1.1	5.5	0.5	1.8	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	7.5	5/8"-10 UNC	0.3	1.8	5.3	1.1	5.5	0.6	2.1	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	9.5	3/4"-10 UNC	0.3	1.8	5.3	1.1	5.5	0.8	2.2	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	11.8	3/4"-10 UNC	0.3	2.4	10.8	1.6	8.3	0.9	2.4	0.7	4	4.9	0.4
10"	8	11.5	1.5	14.3	7/8"-9 UNC	0.5	2.4	10.8	1.6	8.3	1.1	2.6	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	17	7/8"-9 UNC	0.5	3.1	10.8	1.6	8.7	1.3	3.1	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D (in. mm)	M	N	E	⌀F	G	H	⌀Q	L	S	⌀T	⌀U	⌀V
2"	76	162	32	121	5/8"-10 UNC	4	44	135	28	139	12.7	42	10	70	90	9.5
3"	95	181	32	152	5/8"-10 UNC	4	44	135	28	139	12.7	45	10	70	90	9.5
4"	114	200	32	191	5/8"-10 UNC	8	44	135	28	139	15.88	52	12	70	90	9.5
6"	139	225	32	241	3/4"-10 UNC	8	44	135	28	139	19.05	56	14	70	90	9.5
8"	177	260	38	298	3/4"-10 UNC	8	62	275	40	211	22.23	60	17	102	125	11.5
10"	203	292	38	362	7/8"-9 UNC	12	62	275	40	211	28.58	66	22	102	125	11.5
12"	242	337	38	432	7/8"-9 UNC	12	78	275	40	220	31.75	77	24	102	125	11.5

" "

VK-BF-210G

10" Cast Iron Butterfly Valve Lug Style - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Gearbox operator is self-locking in any position for throttle control
• Lug style body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D (in. mm)	M	N	E	⌀F	G	H	⌀Q	L	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	4.8	5/8"-10 UNC	0.2	1.8	5.3	1.1	5.5	0.5	1.6	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	6	5/8"-10 UNC	0.2	1.8	5.3	1.1	5.5	0.5	1.8	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	7.5	5/8"-10 UNC	0.3	1.8	5.3	1.1	5.5	0.6	2.1	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	9.5	3/4"-10 UNC	0.3	1.8	5.3	1.1	5.5	0.8	2.2	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	11.8	3/4"-10 UNC	0.3	2.4	10.8	1.6	8.3	0.9	2.4	0.7	4	4.9	0.4
10"	8	11.5	1.5	14.3	7/8"-9 UNC	0.5	2.4	10.8	1.6	8.3	1.1	2.6	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	17	7/8"-9 UNC	0.5	3.1	10.8	1.6	8.7	1.3	3.1	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D (in. mm)	M	N	E	⌀F	G	H	⌀Q	L	S	⌀T	⌀U	⌀V
2"	76	162	32	121	5/8"-10 UNC	4	44	135	28	139	12.7	42	10	70	90	9.5
3"	95	181	32	152	5/8"-10 UNC	4	44	135	28	139	12.7	45	10	70	90	9.5
4"	114	200	32	191	5/8"-10 UNC	8	44	135	28	139	15.88	52	12	70	90	9.5
6"	139	225	32	241	3/4"-10 UNC	8	44	135	28	139	19.05	56	14	70	90	9.5
8"	177	260	38	298	3/4"-10 UNC	8	62	275	40	211	22.23	60	17	102	125	11.5
10"	203	292	38	362	7/8"-9 UNC	12	62	275	40	211	28.58	66	22	102	125	11.5
12"	242	337	38	432	7/8"-9 UNC	12	78	275	40	220	31.75	77	24	102	125	11.5

" "

VK-BF-212G

12" Cast Iron Butterfly Valve Lug Style - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed. Needs to be installed with flanges. No need for gaskets since they already have a rubber seal.

Features:

• Gearbox operator is self-locking in any position for throttle control
• Lug style body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating
• Does not require flange gaskets thanks to EPDM seat

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D (in. mm)	M	N	E	⌀F	G	H	⌀Q	L	S	⌀T	⌀U	⌀V
2"	3	6.4	1.3	4.8	5/8"-10 UNC	0.2	1.8	5.3	1.1	5.5	0.5	1.6	0.4	2.8	3.6	0.4
3"	3.8	7.1	1.3	6	5/8"-10 UNC	0.2	1.8	5.3	1.1	5.5	0.5	1.8	0.4	2.8	3.6	0.4
4"	4.5	7.9	1.3	7.5	5/8"-10 UNC	0.3	1.8	5.3	1.1	5.5	0.6	2.1	0.5	2.8	3.6	0.4
6"	5.5	8.9	1.3	9.5	3/4"-10 UNC	0.3	1.8	5.3	1.1	5.5	0.8	2.2	0.6	2.8	3.6	0.4
8"	6.9	10.3	1.5	11.8	3/4"-10 UNC	0.3	2.4	10.8	1.6	8.3	0.9	2.4	0.7	4	4.9	0.4
10"	8	11.5	1.5	14.3	7/8"-9 UNC	0.5	2.4	10.8	1.6	8.3	1.1	2.6	0.9	4	4.9	0.4
12"	9.5	13.3	1.5	17	7/8"-9 UNC	0.5	3.1	10.8	1.6	8.7	1.3	3.1	0.9	4	4.9	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D (in. mm)	M	N	E	⌀F	G	H	⌀Q	L	S	⌀T	⌀U	⌀V
2"	76	162	32	121	5/8"-10 UNC	4	44	135	28	139	12.7	42	10	70	90	9.5
3"	95	181	32	152	5/8"-10 UNC	4	44	135	28	139	12.7	45	10	70	90	9.5
4"	114	200	32	191	5/8"-10 UNC	8	44	135	28	139	15.88	52	12	70	90	9.5
6"	139	225	32	241	3/4"-10 UNC	8	44	135	28	139	19.05	56	14	70	90	9.5
8"	177	260	38	298	3/4"-10 UNC	8	62	275	40	211	22.23	60	17	102	125	11.5
10"	203	292	38	362	7/8"-9 UNC	12	62	275	40	211	28.58	66	22	102	125	11.5
12"	242	337	38	432	7/8"-9 UNC	12	78	275	40	220	31.75	77	24	102	125	11.5

" "

VK-BF-303G

3" Ductile Iron Butterfly Valve Flanged Centric - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed.

Features:

• Gearbox operator is self-locking in any position for throttle control
• Flanged body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D	⌀R	N-⌀W	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
3"	3.4	5.9	1.3	7.5	6	4-19 (3/4")	1.8	5.3	1.1	5.5	4.5	0.5	0.4	3.6	2.8	0.4
4"	4.1	6.3	1.3	9	7.5	4-19 (3/4")	1.8	5.3	1.1	5.5	5	0.6	0.5	3.6	2.8	0.4
6"	5.1	7.9	1.3	11	9.5	8-22 (7/8")	1.8	5.3	1.1	5.5	5.5	0.8	0.6	3.6	2.8	0.4
8"	6.3	9.1	1.5	13.5	11.8	8-22 (7/8")	2.4	10.8	1.6	8.3	6	0.9	0.7	4.9	4.1	0.4
10"	7.6	10.3	1.5	16	14.3	12-25 (1")	2.4	10.8	1.6	8.3	6.5	1.1	0.9	4.9	4.1	0.4
12"	8.7	11.8	1.5	19	17	12-25 (1")	3.1	10.8	1.6	8.7	7	1.3	0.9	4.9	4.1	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D	⌀R	N-⌀W	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
3"	85	150	32	191	152.4	4-19 (3/4")	44	135	28	139	114	12.7	10	90	70	9.5
4"	104	160	32	229	190.5	4-19 (3/4")	44	135	28	139	127	15.88	12	90	70	9.5
6"	130	200	32	279	241	8-22 (7/8")	44	135	28	139	140	19.05	14	90	70	9.5
8"	160	230	38	343	298	8-22 (7/8")	62	275	40	211	152	22.23	17	125	105	11.5
10"	194	260	38	406	362	12-25 (1")	62	275	40	211	165	28.58	22	125	105	11.5
12"	220	300	38	483	432	12-25 (1")	78	275	40	220	178	31.75	24	125	105	11.5

" "

VK-BF-304G

4" Ductile Iron Butterfly Valve Flanged Centric - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed.

Features:

• Gearbox operator is self-locking in any position for throttle control
• Flanged body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D	⌀R	N-⌀W	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
3"	3.4	5.9	1.3	7.5	6	4-19 (3/4")	1.8	5.3	1.1	5.5	4.5	0.5	0.4	3.6	2.8	0.4
4"	4.1	6.3	1.3	9	7.5	4-19 (3/4")	1.8	5.3	1.1	5.5	5	0.6	0.5	3.6	2.8	0.4
6"	5.1	7.9	1.3	11	9.5	8-22 (7/8")	1.8	5.3	1.1	5.5	5.5	0.8	0.6	3.6	2.8	0.4
8"	6.3	9.1	1.5	13.5	11.8	8-22 (7/8")	2.4	10.8	1.6	8.3	6	0.9	0.7	4.9	4.1	0.4
10"	7.6	10.3	1.5	16	14.3	12-25 (1")	2.4	10.8	1.6	8.3	6.5	1.1	0.9	4.9	4.1	0.4
12"	8.7	11.8	1.5	19	17	12-25 (1")	3.1	10.8	1.6	8.7	7	1.3	0.9	4.9	4.1	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D	⌀R	N-⌀W	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
3"	85	150	32	191	152.4	4-19 (3/4")	44	135	28	139	114	12.7	10	90	70	9.5
4"	104	160	32	229	190.5	4-19 (3/4")	44	135	28	139	127	15.88	12	90	70	9.5
6"	130	200	32	279	241	8-22 (7/8")	44	135	28	139	140	19.05	14	90	70	9.5
8"	160	230	38	343	298	8-22 (7/8")	62	275	40	211	152	22.23	17	125	105	11.5
10"	194	260	38	406	362	12-25 (1")	62	275	40	211	165	28.58	22	125	105	11.5
12"	220	300	38	483	432	12-25 (1")	78	275	40	220	178	31.75	24	125	105	11.5

" "

VK-BF-306G

6" Ductile Iron Butterfly Valve Flanged Centric - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed.

Features:

• Gearbox operator is self-locking in any position for throttle control
• Flanged body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D	⌀R	N-⌀W	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
3"	3.4	5.9	1.3	7.5	6	4-19 (3/4")	1.8	5.3	1.1	5.5	4.5	0.5	0.4	3.6	2.8	0.4
4"	4.1	6.3	1.3	9	7.5	4-19 (3/4")	1.8	5.3	1.1	5.5	5	0.6	0.5	3.6	2.8	0.4
6"	5.1	7.9	1.3	11	9.5	8-22 (7/8")	1.8	5.3	1.1	5.5	5.5	0.8	0.6	3.6	2.8	0.4
8"	6.3	9.1	1.5	13.5	11.8	8-22 (7/8")	2.4	10.8	1.6	8.3	6	0.9	0.7	4.9	4.1	0.4
10"	7.6	10.3	1.5	16	14.3	12-25 (1")	2.4	10.8	1.6	8.3	6.5	1.1	0.9	4.9	4.1	0.4
12"	8.7	11.8	1.5	19	17	12-25 (1")	3.1	10.8	1.6	8.7	7	1.3	0.9	4.9	4.1	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D	⌀R	N-⌀W	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
3"	85	150	32	191	152.4	4-19 (3/4")	44	135	28	139	114	12.7	10	90	70	9.5
4"	104	160	32	229	190.5	4-19 (3/4")	44	135	28	139	127	15.88	12	90	70	9.5
6"	130	200	32	279	241	8-22 (7/8")	44	135	28	139	140	19.05	14	90	70	9.5
8"	160	230	38	343	298	8-22 (7/8")	62	275	40	211	152	22.23	17	125	105	11.5
10"	194	260	38	406	362	12-25 (1")	62	275	40	211	165	28.58	22	125	105	11.5
12"	220	300	38	483	432	12-25 (1")	78	275	40	220	178	31.75	24	125	105	11.5

" "

VK-BF-308G

8" Ductile Iron Butterfly Valve Flanged Centric - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed.

Features:

• Gearbox operator is self-locking in any position for throttle control
• Flanged body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D	⌀R	N-⌀W	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
3"	3.4	5.9	1.3	7.5	6	4-19 (3/4")	1.8	5.3	1.1	5.5	4.5	0.5	0.4	3.6	2.8	0.4
4"	4.1	6.3	1.3	9	7.5	4-19 (3/4")	1.8	5.3	1.1	5.5	5	0.6	0.5	3.6	2.8	0.4
6"	5.1	7.9	1.3	11	9.5	8-22 (7/8")	1.8	5.3	1.1	5.5	5.5	0.8	0.6	3.6	2.8	0.4
8"	6.3	9.1	1.5	13.5	11.8	8-22 (7/8")	2.4	10.8	1.6	8.3	6	0.9	0.7	4.9	4.1	0.4
10"	7.6	10.3	1.5	16	14.3	12-25 (1")	2.4	10.8	1.6	8.3	6.5	1.1	0.9	4.9	4.1	0.4
12"	8.7	11.8	1.5	19	17	12-25 (1")	3.1	10.8	1.6	8.7	7	1.3	0.9	4.9	4.1	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D	⌀R	N-⌀W	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
3"	85	150	32	191	152.4	4-19 (3/4")	44	135	28	139	114	12.7	10	90	70	9.5
4"	104	160	32	229	190.5	4-19 (3/4")	44	135	28	139	127	15.88	12	90	70	9.5
6"	130	200	32	279	241	8-22 (7/8")	44	135	28	139	140	19.05	14	90	70	9.5
8"	160	230	38	343	298	8-22 (7/8")	62	275	40	211	152	22.23	17	125	105	11.5
10"	194	260	38	406	362	12-25 (1")	62	275	40	211	165	28.58	22	125	105	11.5
12"	220	300	38	483	432	12-25 (1")	78	275	40	220	178	31.75	24	125	105	11.5

" "

VK-BF-310G

10" Ductile Iron Butterfly Valve Flanged Centric - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed.

Features:

• Gearbox operator is self-locking in any position for throttle control
• Flanged body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D	⌀R	N-⌀W	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
3"	3.4	5.9	1.3	7.5	6	4-19 (3/4")	1.8	5.3	1.1	5.5	4.5	0.5	0.4	3.6	2.8	0.4
4"	4.1	6.3	1.3	9	7.5	4-19 (3/4")	1.8	5.3	1.1	5.5	5	0.6	0.5	3.6	2.8	0.4
6"	5.1	7.9	1.3	11	9.5	8-22 (7/8")	1.8	5.3	1.1	5.5	5.5	0.8	0.6	3.6	2.8	0.4
8"	6.3	9.1	1.5	13.5	11.8	8-22 (7/8")	2.4	10.8	1.6	8.3	6	0.9	0.7	4.9	4.1	0.4
10"	7.6	10.3	1.5	16	14.3	12-25 (1")	2.4	10.8	1.6	8.3	6.5	1.1	0.9	4.9	4.1	0.4
12"	8.7	11.8	1.5	19	17	12-25 (1")	3.1	10.8	1.6	8.7	7	1.3	0.9	4.9	4.1	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D	⌀R	N-⌀W	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
3"	85	150	32	191	152.4	4-19 (3/4")	44	135	28	139	114	12.7	10	90	70	9.5
4"	104	160	32	229	190.5	4-19 (3/4")	44	135	28	139	127	15.88	12	90	70	9.5
6"	130	200	32	279	241	8-22 (7/8")	44	135	28	139	140	19.05	14	90	70	9.5
8"	160	230	38	343	298	8-22 (7/8")	62	275	40	211	152	22.23	17	125	105	11.5
10"	194	260	38	406	362	12-25 (1")	62	275	40	211	165	28.58	22	125	105	11.5
12"	220	300	38	483	432	12-25 (1")	78	275	40	220	178	31.75	24	125	105	11.5

" "

VK-BF-312G

12" Ductile Iron Butterfly Valve Flanged Centric - EPDM Seat, Gear Operated

The butterfly valve is a rotary valve in which a disk-shaped seating element is rotated 90° to open or close the flow passage. Can be left partially open or closed for flow throttling. Butterfly valves cannot be used where a non obstructed full opening is needed.

Features:

• Gearbox operator is self-locking in any position for throttle control
• Flanged body design offers dead-end service without the use of a downstream companion flange
• Fusion-Bonded Epoxy Coating

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	⌀D	⌀R	N-⌀W	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
3"	3.4	5.9	1.3	7.5	6	4-19 (3/4")	1.8	5.3	1.1	5.5	4.5	0.5	0.4	3.6	2.8	0.4
4"	4.1	6.3	1.3	9	7.5	4-19 (3/4")	1.8	5.3	1.1	5.5	5	0.6	0.5	3.6	2.8	0.4
6"	5.1	7.9	1.3	11	9.5	8-22 (7/8")	1.8	5.3	1.1	5.5	5.5	0.8	0.6	3.6	2.8	0.4
8"	6.3	9.1	1.5	13.5	11.8	8-22 (7/8")	2.4	10.8	1.6	8.3	6	0.9	0.7	4.9	4.1	0.4
10"	7.6	10.3	1.5	16	14.3	12-25 (1")	2.4	10.8	1.6	8.3	6.5	1.1	0.9	4.9	4.1	0.4
12"	8.7	11.8	1.5	19	17	12-25 (1")	3.1	10.8	1.6	8.7	7	1.3	0.9	4.9	4.1	0.4

Dimensions - Millimeters

Size	A	B	C	⌀D	⌀R	N-⌀W	E	⌀F	G	H	L	⌀Q	S	⌀T	⌀U	⌀V
3"	85	150	32	191	152.4	4-19 (3/4")	44	135	28	139	114	12.7	10	90	70	9.5
4"	104	160	32	229	190.5	4-19 (3/4")	44	135	28	139	127	15.88	12	90	70	9.5
6"	130	200	32	279	241	8-22 (7/8")	44	135	28	139	140	19.05	14	90	70	9.5
8"	160	230	38	343	298	8-22 (7/8")	62	275	40	211	152	22.23	17	125	105	11.5
10"	194	260	38	406	362	12-25 (1")	62	275	40	211	165	28.58	22	125	105	11.5
12"	220	300	38	483	432	12-25 (1")	78	275	40	220	178	31.75	24	125	105	11.5

" "

RKEV2

2" Brass Gate Valve Reduced Bore

• Product contains brass which does not meet federal and state requirements for drinking water.

Material:

• Body: Brass
• Stem: Brass
• Press Nut: Brass
• Handle: Iron

" "

RKGV2

2" Brass Gate Valve

• Product contains brass which does not meet federal and state requirements for drinking water.

Material:

• Body: Brass
• Stem: Brass
• Press Nut: Brass
• Handle: Iron

" "

RKGV3

3" Brass Gate Valve

• Product contains brass which does not meet federal and state requirements for drinking water.

Material:

• Body: Brass
• Stem: Brass
• Press Nut: Brass
• Handle: Iron

" "

RKGV4

4" Brass Gate Valve

• Product contains brass which does not meet federal and state requirements for drinking water.

Material:

• Body: Brass
• Stem: Brass
• Press Nut: Brass
• Handle: Iron

" "

RKT2

2" Ductile Iron Gate Valve, FLG, NRS, Resilient Wedge, Handwheel, AWWA C515

On a standard gate valve with only a metal seal there needs to be a impression for the gate to seat to and make a seal. This impression can get dirt, pebbles, sand or other debris trapped in it, eventually losing its ability to seal 100%. The advantage our resilient seated gate valve has is that the opening in the valve is completely smooth, preventing debris from getting stuck. Even with some impurities the rubber surface will be able to conform and seal.

Features:

• Non-Rising Stem
• Resilient Wedge
• Fusion-Bonded Epoxy Coating Inside & Outside
• Flanges Conform to ANSI B16.1

Material:

• Body: Ductile Iron
• Bonnet: Ductile Iron
• Wedge: EPDM Covered Ductile Iron
• Stem: Stainless Steel SS420
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	DN	L	D	F	C	n-d
2"	1.9	7	5.9	4.8	0.6	4-19 (3/4")
3"	3.1	8	7.5	6	0.8	4-19 (3/4")
4"	3.9	9	9	7.5	0.9	8-19 (3/4")
6"	5.9	10.5	11	9.5	1	8-22 (7/8")
8"	7.9	11.5	13.5	11.8	1.1	8-22 (7/8")
10"	9.8	13	16	14.3	1.2	12-25 (1")
12"	11.8	14	19	17	1.3	12-25 (1")

Dimensions - Millimeters

Size	DN	L	D	F	C	n-d
2"	50	178	150	120.5	15.9	4-19 (3/4")
3"	80	203	190	152.5	19.1	4-19 (3/4")
4"	100	229	229	190.5	23.9	8-19 (3/4")
6"	150	267	279	241.5	25.4	8-22 (7/8")
8"	200	292	343	298.5	28.6	8-22 (7/8")
10"	250	330	406	362.5	30.2	12-25 (1")
12"	300	356	483	432	31.8	12-25 (1")

" "

RKT3

3" Ductile Iron Gate Valve, FLG, NRS, Resilient Wedge, Handwheel, AWWA C515

On a standard gate valve with only a metal seal there needs to be a impression for the gate to seat to and make a seal. This impression can get dirt, pebbles, sand or other debris trapped in it, eventually losing its ability to seal 100%. The advantage our resilient seated gate valve has is that the opening in the valve is completely smooth, preventing debris from getting stuck. Even with some impurities the rubber surface will be able to conform and seal.

Features:

• Non-Rising Stem
• Resilient Wedge
• Fusion-Bonded Epoxy Coating Inside & Outside
• Flanges Conform to ANSI B16.1

Material:

• Body: Ductile Iron
• Bonnet: Ductile Iron
• Wedge: EPDM Covered Ductile Iron
• Stem: Stainless Steel SS420
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	DN	L	D	F	C	n-d
2"	1.9	7	5.9	4.8	0.6	4-19 (3/4")
3"	3.1	8	7.5	6	0.8	4-19 (3/4")
4"	3.9	9	9	7.5	0.9	8-19 (3/4")
6"	5.9	10.5	11	9.5	1	8-22 (7/8")
8"	7.9	11.5	13.5	11.8	1.1	8-22 (7/8")
10"	9.8	13	16	14.3	1.2	12-25 (1")
12"	11.8	14	19	17	1.3	12-25 (1")

Dimensions - Millimeters

Size	DN	L	D	F	C	n-d
2"	50	178	150	120.5	15.9	4-19 (3/4")
3"	80	203	190	152.5	19.1	4-19 (3/4")
4"	100	229	229	190.5	23.9	8-19 (3/4")
6"	150	267	279	241.5	25.4	8-22 (7/8")
8"	200	292	343	298.5	28.6	8-22 (7/8")
10"	250	330	406	362.5	30.2	12-25 (1")
12"	300	356	483	432	31.8	12-25 (1")

" "

RKT4

4" Ductile Iron Gate Valve, FLG, NRS, Resilient Wedge, Handwheel, AWWA C515

On a standard gate valve with only a metal seal there needs to be a impression for the gate to seat to and make a seal. This impression can get dirt, pebbles, sand or other debris trapped in it, eventually losing its ability to seal 100%. The advantage our resilient seated gate valve has is that the opening in the valve is completely smooth, preventing debris from getting stuck. Even with some impurities the rubber surface will be able to conform and seal.

Features:

• Non-Rising Stem
• Resilient Wedge
• Fusion-Bonded Epoxy Coating Inside & Outside
• Flanges Conform to ANSI B16.1

Material:

• Body: Ductile Iron
• Bonnet: Ductile Iron
• Wedge: EPDM Covered Ductile Iron
• Stem: Stainless Steel SS420
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	DN	L	D	F	C	n-d
2"	1.9	7	5.9	4.8	0.6	4-19 (3/4")
3"	3.1	8	7.5	6	0.8	4-19 (3/4")
4"	3.9	9	9	7.5	0.9	8-19 (3/4")
6"	5.9	10.5	11	9.5	1	8-22 (7/8")
8"	7.9	11.5	13.5	11.8	1.1	8-22 (7/8")
10"	9.8	13	16	14.3	1.2	12-25 (1")
12"	11.8	14	19	17	1.3	12-25 (1")

Dimensions - Millimeters

Size	DN	L	D	F	C	n-d
2"	50	178	150	120.5	15.9	4-19 (3/4")
3"	80	203	190	152.5	19.1	4-19 (3/4")
4"	100	229	229	190.5	23.9	8-19 (3/4")
6"	150	267	279	241.5	25.4	8-22 (7/8")
8"	200	292	343	298.5	28.6	8-22 (7/8")
10"	250	330	406	362.5	30.2	12-25 (1")
12"	300	356	483	432	31.8	12-25 (1")

" "

RKT6

6" Ductile Iron Gate Valve, FLG, NRS, Resilient Wedge, Handwheel, AWWA C515

On a standard gate valve with only a metal seal there needs to be a impression for the gate to seat to and make a seal. This impression can get dirt, pebbles, sand or other debris trapped in it, eventually losing its ability to seal 100%. The advantage our resilient seated gate valve has is that the opening in the valve is completely smooth, preventing debris from getting stuck. Even with some impurities the rubber surface will be able to conform and seal.

Features:

• Non-Rising Stem
• Resilient Wedge
• Fusion-Bonded Epoxy Coating Inside & Outside
• Flanges Conform to ANSI B16.1

Material:

• Body: Ductile Iron
• Bonnet: Ductile Iron
• Wedge: EPDM Covered Ductile Iron
• Stem: Stainless Steel SS420
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	DN	L	D	F	C	n-d
2"	1.9	7	5.9	4.8	0.6	4-19 (3/4")
3"	3.1	8	7.5	6	0.8	4-19 (3/4")
4"	3.9	9	9	7.5	0.9	8-19 (3/4")
6"	5.9	10.5	11	9.5	1	8-22 (7/8")
8"	7.9	11.5	13.5	11.8	1.1	8-22 (7/8")
10"	9.8	13	16	14.3	1.2	12-25 (1")
12"	11.8	14	19	17	1.3	12-25 (1")

Dimensions - Millimeters

Size	DN	L	D	F	C	n-d
2"	50	178	150	120.5	15.9	4-19 (3/4")
3"	80	203	190	152.5	19.1	4-19 (3/4")
4"	100	229	229	190.5	23.9	8-19 (3/4")
6"	150	267	279	241.5	25.4	8-22 (7/8")
8"	200	292	343	298.5	28.6	8-22 (7/8")
10"	250	330	406	362.5	30.2	12-25 (1")
12"	300	356	483	432	31.8	12-25 (1")

" "

RKT8

8" Ductile Iron Gate Valve, FLG, NRS, Resilient Wedge, Handwheel, AWWA C515

On a standard gate valve with only a metal seal there needs to be a impression for the gate to seat to and make a seal. This impression can get dirt, pebbles, sand or other debris trapped in it, eventually losing its ability to seal 100%. The advantage our resilient seated gate valve has is that the opening in the valve is completely smooth, preventing debris from getting stuck. Even with some impurities the rubber surface will be able to conform and seal.

Features:

• Non-Rising Stem
• Resilient Wedge
• Fusion-Bonded Epoxy Coating Inside & Outside
• Flanges Conform to ANSI B16.1

Material:

• Body: Ductile Iron
• Bonnet: Ductile Iron
• Wedge: EPDM Covered Ductile Iron
• Stem: Stainless Steel SS420
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	DN	L	D	F	C	n-d
2"	1.9	7	5.9	4.8	0.6	4-19 (3/4")
3"	3.1	8	7.5	6	0.8	4-19 (3/4")
4"	3.9	9	9	7.5	0.9	8-19 (3/4")
6"	5.9	10.5	11	9.5	1	8-22 (7/8")
8"	7.9	11.5	13.5	11.8	1.1	8-22 (7/8")
10"	9.8	13	16	14.3	1.2	12-25 (1")
12"	11.8	14	19	17	1.3	12-25 (1")

Dimensions - Millimeters

Size	DN	L	D	F	C	n-d
2"	50	178	150	120.5	15.9	4-19 (3/4")
3"	80	203	190	152.5	19.1	4-19 (3/4")
4"	100	229	229	190.5	23.9	8-19 (3/4")
6"	150	267	279	241.5	25.4	8-22 (7/8")
8"	200	292	343	298.5	28.6	8-22 (7/8")
10"	250	330	406	362.5	30.2	12-25 (1")
12"	300	356	483	432	31.8	12-25 (1")

" "

RKT10

10" Ductile Iron Gate Valve, FLG, NRS, Resilient Wedge, Handwheel, AWWA C515

On a standard gate valve with only a metal seal there needs to be a impression for the gate to seat to and make a seal. This impression can get dirt, pebbles, sand or other debris trapped in it, eventually losing its ability to seal 100%. The advantage our resilient seated gate valve has is that the opening in the valve is completely smooth, preventing debris from getting stuck. Even with some impurities the rubber surface will be able to conform and seal.

Features:

• Non-Rising Stem
• Resilient Wedge
• Fusion-Bonded Epoxy Coating Inside & Outside
• Flanges Conform to ANSI B16.1

Material:

• Body: Ductile Iron
• Bonnet: Ductile Iron
• Wedge: EPDM Covered Ductile Iron
• Stem: Stainless Steel SS420
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	DN	L	D	F	C	n-d
2"	1.9	7	5.9	4.8	0.6	4-19 (3/4")
3"	3.1	8	7.5	6	0.8	4-19 (3/4")
4"	3.9	9	9	7.5	0.9	8-19 (3/4")
6"	5.9	10.5	11	9.5	1	8-22 (7/8")
8"	7.9	11.5	13.5	11.8	1.1	8-22 (7/8")
10"	9.8	13	16	14.3	1.2	12-25 (1")
12"	11.8	14	19	17	1.3	12-25 (1")

Dimensions - Millimeters

Size	DN	L	D	F	C	n-d
2"	50	178	150	120.5	15.9	4-19 (3/4")
3"	80	203	190	152.5	19.1	4-19 (3/4")
4"	100	229	229	190.5	23.9	8-19 (3/4")
6"	150	267	279	241.5	25.4	8-22 (7/8")
8"	200	292	343	298.5	28.6	8-22 (7/8")
10"	250	330	406	362.5	30.2	12-25 (1")
12"	300	356	483	432	31.8	12-25 (1")

" "

RKT12

12" Ductile Iron Gate Valve, FLG, NRS, Resilient Wedge, Handwheel, AWWA C515

On a standard gate valve with only a metal seal there needs to be a impression for the gate to seat to and make a seal. This impression can get dirt, pebbles, sand or other debris trapped in it, eventually losing its ability to seal 100%. The advantage our resilient seated gate valve has is that the opening in the valve is completely smooth, preventing debris from getting stuck. Even with some impurities the rubber surface will be able to conform and seal.

Features:

• Non-Rising Stem
• Resilient Wedge
• Fusion-Bonded Epoxy Coating Inside & Outside
• Flanges Conform to ANSI B16.1

Material:

• Body: Ductile Iron
• Bonnet: Ductile Iron
• Wedge: EPDM Covered Ductile Iron
• Stem: Stainless Steel SS420
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	DN	L	D	F	C	n-d
2"	1.9	7	5.9	4.8	0.6	4-19 (3/4")
3"	3.1	8	7.5	6	0.8	4-19 (3/4")
4"	3.9	9	9	7.5	0.9	8-19 (3/4")
6"	5.9	10.5	11	9.5	1	8-22 (7/8")
8"	7.9	11.5	13.5	11.8	1.1	8-22 (7/8")
10"	9.8	13	16	14.3	1.2	12-25 (1")
12"	11.8	14	19	17	1.3	12-25 (1")

Dimensions - Millimeters

Size	DN	L	D	F	C	n-d
2"	50	178	150	120.5	15.9	4-19 (3/4")
3"	80	203	190	152.5	19.1	4-19 (3/4")
4"	100	229	229	190.5	23.9	8-19 (3/4")
6"	150	267	279	241.5	25.4	8-22 (7/8")
8"	200	292	343	298.5	28.6	8-22 (7/8")
10"	250	330	406	362.5	30.2	12-25 (1")
12"	300	356	483	432	31.8	12-25 (1")

" "

VK-GT-403-RS

3" Ductile Iron Gate Valve, FLG, Rising Stem, Resilient Wedge, Handwheel, AWWA C515

On a standard gate valve with only a metal seal there needs to be a impression for the gate to seat to and make a seal. This impression can get dirt, pebbles, sand or other debris trapped in it, eventually losing its ability to seal 100%. The advantage our resilient seated gate valve has is that the opening in the valve is completely smooth, preventing debris from getting stuck. Even with some impurities the rubber surface will be able to conform and seal.

Features:

• Rising Stem
• Resilient Wedge
• Fusion Bonded Epoxy Coated Interior and Exterior to AWWA C550 Standard
• Flanges Conform to ANSI B16.1

Material:

• Body: Ductile Iron
• Bonnet: Ductile Iron
• Wedge: EPDM Covered Ductile Iron
• Stem: Stainless Steel SS420
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	DN	L	D	K	B	n-d	H
2"	1.9	7	6	4.8	0.6	4-19 (3/4")	10.1
3"	3.1	8	7.5	6	0.8	4-19 (3/4")	13.6
4"	3.9	9	9	7.5	0.9	8-19 (3/4")	16.6
6"	5.9	10.5	11	9.5	1	8-22 (7/8")	20.1
8"	7.9	11.5	13.5	11.8	1.1	8-22 (7/8")	27.9
10"	9.8	13	16	14.3	1.2	12-25 (1")	31.3
12"	11.8	14	19	17	1.3	12-25 (1")	37.4

Dimensions - Millimeters

Size	DN	L	D	K	B	n-d	H
2"	50	178	152	120.5	16	4-19 (3/4")	255
3"	80	203	191	152.5	19	4-19 (3/4")	345
4"	100	229	229	190.5	24	8-19 (3/4")	420
6"	150	267	279	241.5	26	8-22 (7/8")	510
8"	200	292	343	298.5	28	8-22 (7/8")	710
10"	250	330	406	362.5	30	12-25 (1")	795
12"	300	356	483	432	32	12-25 (1")	950

" "

VK-GT-404-RS

4" Ductile Iron Gate Valve, FLG, Rising Stem, Resilient Wedge, Handwheel, AWWA C515

On a standard gate valve with only a metal seal there needs to be a impression for the gate to seat to and make a seal. This impression can get dirt, pebbles, sand or other debris trapped in it, eventually losing its ability to seal 100%. The advantage our resilient seated gate valve has is that the opening in the valve is completely smooth, preventing debris from getting stuck. Even with some impurities the rubber surface will be able to conform and seal.

Features:

• Rising Stem
• Resilient Wedge
• Fusion Bonded Epoxy Coated Interior and Exterior to AWWA C550 Standard
• Flanges Conform to ANSI B16.1

Material:

• Body: Ductile Iron
• Bonnet: Ductile Iron
• Wedge: EPDM Covered Ductile Iron
• Stem: Stainless Steel SS420
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	DN	L	D	K	B	n-d	H
2"	1.9	7	6	4.8	0.6	4-19 (3/4")	10.1
3"	3.1	8	7.5	6	0.8	4-19 (3/4")	13.6
4"	3.9	9	9	7.5	0.9	8-19 (3/4")	16.6
6"	5.9	10.5	11	9.5	1	8-22 (7/8")	20.1
8"	7.9	11.5	13.5	11.8	1.1	8-22 (7/8")	27.9
10"	9.8	13	16	14.3	1.2	12-25 (1")	31.3
12"	11.8	14	19	17	1.3	12-25 (1")	37.4

Dimensions - Millimeters

Size	DN	L	D	K	B	n-d	H
2"	50	178	152	120.5	16	4-19 (3/4")	255
3"	80	203	191	152.5	19	4-19 (3/4")	345
4"	100	229	229	190.5	24	8-19 (3/4")	420
6"	150	267	279	241.5	26	8-22 (7/8")	510
8"	200	292	343	298.5	28	8-22 (7/8")	710
10"	250	330	406	362.5	30	12-25 (1")	795
12"	300	356	483	432	32	12-25 (1")	950

" "

VK-GT-406-RS

6" Ductile Iron Gate Valve, FLG, Rising Stem, Resilient Wedge, Handwheel, AWWA C515

On a standard gate valve with only a metal seal there needs to be a impression for the gate to seat to and make a seal. This impression can get dirt, pebbles, sand or other debris trapped in it, eventually losing its ability to seal 100%. The advantage our resilient seated gate valve has is that the opening in the valve is completely smooth, preventing debris from getting stuck. Even with some impurities the rubber surface will be able to conform and seal.

Features:

• Rising Stem
• Resilient Wedge
• Fusion Bonded Epoxy Coated Interior and Exterior to AWWA C550 Standard
• Flanges Conform to ANSI B16.1

Material:

• Body: Ductile Iron
• Bonnet: Ductile Iron
• Wedge: EPDM Covered Ductile Iron
• Stem: Stainless Steel SS420
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	DN	L	D	K	B	n-d	H
2"	1.9	7	6	4.8	0.6	4-19 (3/4")	10.1
3"	3.1	8	7.5	6	0.8	4-19 (3/4")	13.6
4"	3.9	9	9	7.5	0.9	8-19 (3/4")	16.6
6"	5.9	10.5	11	9.5	1	8-22 (7/8")	20.1
8"	7.9	11.5	13.5	11.8	1.1	8-22 (7/8")	27.9
10"	9.8	13	16	14.3	1.2	12-25 (1")	31.3
12"	11.8	14	19	17	1.3	12-25 (1")	37.4

Dimensions - Millimeters

Size	DN	L	D	K	B	n-d	H
2"	50	178	152	120.5	16	4-19 (3/4")	255
3"	80	203	191	152.5	19	4-19 (3/4")	345
4"	100	229	229	190.5	24	8-19 (3/4")	420
6"	150	267	279	241.5	26	8-22 (7/8")	510
8"	200	292	343	298.5	28	8-22 (7/8")	710
10"	250	330	406	362.5	30	12-25 (1")	795
12"	300	356	483	432	32	12-25 (1")	950

" "

VK-GT-408-RS

8" Ductile Iron Gate Valve, FLG, Rising Stem, Resilient Wedge, Handwheel, AWWA C515

On a standard gate valve with only a metal seal there needs to be a impression for the gate to seat to and make a seal. This impression can get dirt, pebbles, sand or other debris trapped in it, eventually losing its ability to seal 100%. The advantage our resilient seated gate valve has is that the opening in the valve is completely smooth, preventing debris from getting stuck. Even with some impurities the rubber surface will be able to conform and seal.

Features:

• Rising Stem
• Resilient Wedge
• Fusion Bonded Epoxy Coated Interior and Exterior to AWWA C550 Standard
• Flanges Conform to ANSI B16.1

Material:

• Body: Ductile Iron
• Bonnet: Ductile Iron
• Wedge: EPDM Covered Ductile Iron
• Stem: Stainless Steel SS420
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	DN	L	D	K	B	n-d	H
2"	1.9	7	6	4.8	0.6	4-19 (3/4")	10.1
3"	3.1	8	7.5	6	0.8	4-19 (3/4")	13.6
4"	3.9	9	9	7.5	0.9	8-19 (3/4")	16.6
6"	5.9	10.5	11	9.5	1	8-22 (7/8")	20.1
8"	7.9	11.5	13.5	11.8	1.1	8-22 (7/8")	27.9
10"	9.8	13	16	14.3	1.2	12-25 (1")	31.3
12"	11.8	14	19	17	1.3	12-25 (1")	37.4

Dimensions - Millimeters

Size	DN	L	D	K	B	n-d	H
2"	50	178	152	120.5	16	4-19 (3/4")	255
3"	80	203	191	152.5	19	4-19 (3/4")	345
4"	100	229	229	190.5	24	8-19 (3/4")	420
6"	150	267	279	241.5	26	8-22 (7/8")	510
8"	200	292	343	298.5	28	8-22 (7/8")	710
10"	250	330	406	362.5	30	12-25 (1")	795
12"	300	356	483	432	32	12-25 (1")	950

" "

VK-GT-403MJ

3" Ductile Iron Gate Valve, MJ, NRS, Resilient Wedge, 2" Sq. Nut, AWWA C515

On a standard gate valve with only a metal seal there needs to be a impression for the gate to seat to and make a seal. This impression can get dirt, pebbles, sand or other debris trapped in it, eventually losing its ability to seal 100%. The advantage our resilient seated gate valve has is that the opening in the valve is completely smooth, preventing debris from getting stuck. Even with some impurities the rubber surface will be able to conform and seal.

Features:

• Non-Rising Stem
• Resilient Wedge
• 2" Square Operating Nut
• Fusion Bonded Epoxy Coated Interior and Exterior to AWWA C550 Standard
• Mechanical Joint Connections

Material:

• Body: Ductile Iron
• Bonnet: Ductile Iron
• Wedge: EPDM Covered Ductile Iron
• Stem: Stainless Steel SS420
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	L	H	C	D	b	n-d	A	E	B
3"	8	11.1	6.2	7.7	0.8	4-19 (3/4)	4.9	2.5	4.1
4"	9	13.8	7.5	9.1	0.8	4-22 (7/8)	6	2.5	4.9
6"	10.5	17.8	9.5	11.1	0.8	6-22 (7/8)	8.1	2.5	7
8"	11.5	22	11.8	13.4	0.9	6-22 (7/8)	10.3	2.5	9.2
10"	13	26.3	14	15.6	0.9	8-22 (7/8)	12.4	2.5	11.3
12"	14	29.6	16.3	17.9	1	8-22 (7/8)	14.4	2.5	13.3

Dimensions - Millimeters

Size	L	H	C	D	b	n-d	A	E	B
3"	203	283	157	195	19.1	4-19 (3/4)	126	63.5	104
4"	229	351	191	231	19.1	4-22 (7/8)	153	63.5	125
6"	267	453	241	282	19.1	6-22 (7/8)	207	63.5	178
8"	292	559	299	340	22.2	6-22 (7/8)	261	63.5	233
10"	330	668	356	397	23.8	8-22 (7/8)	314	63.5	285
12"	356	753	413	454	25.4	8-22 (7/8)	367	63.5	338

" "

VK-GT-404MJ

4" Ductile Iron Gate Valve, MJ, NRS, Resilient Wedge, 2" Sq. Nut, AWWA C515

On a standard gate valve with only a metal seal there needs to be a impression for the gate to seat to and make a seal. This impression can get dirt, pebbles, sand or other debris trapped in it, eventually losing its ability to seal 100%. The advantage our resilient seated gate valve has is that the opening in the valve is completely smooth, preventing debris from getting stuck. Even with some impurities the rubber surface will be able to conform and seal.

Features:

• Non-Rising Stem
• Resilient Wedge
• 2" Square Operating Nut
• Fusion Bonded Epoxy Coated Interior and Exterior to AWWA C550 Standard
• Mechanical Joint Connections

Material:

• Body: Ductile Iron
• Bonnet: Ductile Iron
• Wedge: EPDM Covered Ductile Iron
• Stem: Stainless Steel SS420
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	L	H	C	D	b	n-d	A	E	B
3"	8	11.1	6.2	7.7	0.8	4-19 (3/4)	4.9	2.5	4.1
4"	9	13.8	7.5	9.1	0.8	4-22 (7/8)	6	2.5	4.9
6"	10.5	17.8	9.5	11.1	0.8	6-22 (7/8)	8.1	2.5	7
8"	11.5	22	11.8	13.4	0.9	6-22 (7/8)	10.3	2.5	9.2
10"	13	26.3	14	15.6	0.9	8-22 (7/8)	12.4	2.5	11.3
12"	14	29.6	16.3	17.9	1	8-22 (7/8)	14.4	2.5	13.3

Dimensions - Millimeters

Size	L	H	C	D	b	n-d	A	E	B
3"	203	283	157	195	19.1	4-19 (3/4)	126	63.5	104
4"	229	351	191	231	19.1	4-22 (7/8)	153	63.5	125
6"	267	453	241	282	19.1	6-22 (7/8)	207	63.5	178
8"	292	559	299	340	22.2	6-22 (7/8)	261	63.5	233
10"	330	668	356	397	23.8	8-22 (7/8)	314	63.5	285
12"	356	753	413	454	25.4	8-22 (7/8)	367	63.5	338

" "

VK-GT-406MJ

6" Ductile Iron Gate Valve, MJ, NRS, Resilient Wedge, 2" Sq. Nut, AWWA C515

On a standard gate valve with only a metal seal there needs to be a impression for the gate to seat to and make a seal. This impression can get dirt, pebbles, sand or other debris trapped in it, eventually losing its ability to seal 100%. The advantage our resilient seated gate valve has is that the opening in the valve is completely smooth, preventing debris from getting stuck. Even with some impurities the rubber surface will be able to conform and seal.

Features:

• Non-Rising Stem
• Resilient Wedge
• 2" Square Operating Nut
• Fusion Bonded Epoxy Coated Interior and Exterior to AWWA C550 Standard
• Mechanical Joint Connections

Material:

• Body: Ductile Iron
• Bonnet: Ductile Iron
• Wedge: EPDM Covered Ductile Iron
• Stem: Stainless Steel SS420
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	L	H	C	D	b	n-d	A	E	B
3"	8	11.1	6.2	7.7	0.8	4-19 (3/4)	4.9	2.5	4.1
4"	9	13.8	7.5	9.1	0.8	4-22 (7/8)	6	2.5	4.9
6"	10.5	17.8	9.5	11.1	0.8	6-22 (7/8)	8.1	2.5	7
8"	11.5	22	11.8	13.4	0.9	6-22 (7/8)	10.3	2.5	9.2
10"	13	26.3	14	15.6	0.9	8-22 (7/8)	12.4	2.5	11.3
12"	14	29.6	16.3	17.9	1	8-22 (7/8)	14.4	2.5	13.3

Dimensions - Millimeters

Size	L	H	C	D	b	n-d	A	E	B
3"	203	283	157	195	19.1	4-19 (3/4)	126	63.5	104
4"	229	351	191	231	19.1	4-22 (7/8)	153	63.5	125
6"	267	453	241	282	19.1	6-22 (7/8)	207	63.5	178
8"	292	559	299	340	22.2	6-22 (7/8)	261	63.5	233
10"	330	668	356	397	23.8	8-22 (7/8)	314	63.5	285
12"	356	753	413	454	25.4	8-22 (7/8)	367	63.5	338

" "

VK-GT-408MJ

8" Ductile Iron Gate Valve, MJ, NRS, Resilient Wedge, 2" Sq. Nut, AWWA C515

On a standard gate valve with only a metal seal there needs to be a impression for the gate to seat to and make a seal. This impression can get dirt, pebbles, sand or other debris trapped in it, eventually losing its ability to seal 100%. The advantage our resilient seated gate valve has is that the opening in the valve is completely smooth, preventing debris from getting stuck. Even with some impurities the rubber surface will be able to conform and seal.

Features:

• Non-Rising Stem
• Resilient Wedge
• 2" Square Operating Nut
• Fusion Bonded Epoxy Coated Interior and Exterior to AWWA C550 Standard
• Mechanical Joint Connections

Material:

• Body: Ductile Iron
• Bonnet: Ductile Iron
• Wedge: EPDM Covered Ductile Iron
• Stem: Stainless Steel SS420
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	L	H	C	D	b	n-d	A	E	B
3"	8	11.1	6.2	7.7	0.8	4-19 (3/4)	4.9	2.5	4.1
4"	9	13.8	7.5	9.1	0.8	4-22 (7/8)	6	2.5	4.9
6"	10.5	17.8	9.5	11.1	0.8	6-22 (7/8)	8.1	2.5	7
8"	11.5	22	11.8	13.4	0.9	6-22 (7/8)	10.3	2.5	9.2
10"	13	26.3	14	15.6	0.9	8-22 (7/8)	12.4	2.5	11.3
12"	14	29.6	16.3	17.9	1	8-22 (7/8)	14.4	2.5	13.3

Dimensions - Millimeters

Size	L	H	C	D	b	n-d	A	E	B
3"	203	283	157	195	19.1	4-19 (3/4)	126	63.5	104
4"	229	351	191	231	19.1	4-22 (7/8)	153	63.5	125
6"	267	453	241	282	19.1	6-22 (7/8)	207	63.5	178
8"	292	559	299	340	22.2	6-22 (7/8)	261	63.5	233
10"	330	668	356	397	23.8	8-22 (7/8)	314	63.5	285
12"	356	753	413	454	25.4	8-22 (7/8)	367	63.5	338

" "

VK-GT-410MJ

10" Ductile Iron Gate Valve, MJ, NRS, Resilient Wedge, 2" Sq. Nut, AWWA C515

On a standard gate valve with only a metal seal there needs to be a impression for the gate to seat to and make a seal. This impression can get dirt, pebbles, sand or other debris trapped in it, eventually losing its ability to seal 100%. The advantage our resilient seated gate valve has is that the opening in the valve is completely smooth, preventing debris from getting stuck. Even with some impurities the rubber surface will be able to conform and seal.

Features:

• Non-Rising Stem
• Resilient Wedge
• 2" Square Operating Nut
• Fusion Bonded Epoxy Coated Interior and Exterior to AWWA C550 Standard
• Mechanical Joint Connections

Material:

• Body: Ductile Iron
• Bonnet: Ductile Iron
• Wedge: EPDM Covered Ductile Iron
• Stem: Stainless Steel SS420
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	L	H	C	D	b	n-d	A	E	B
3"	8	11.1	6.2	7.7	0.8	4-19 (3/4)	4.9	2.5	4.1
4"	9	13.8	7.5	9.1	0.8	4-22 (7/8)	6	2.5	4.9
6"	10.5	17.8	9.5	11.1	0.8	6-22 (7/8)	8.1	2.5	7
8"	11.5	22	11.8	13.4	0.9	6-22 (7/8)	10.3	2.5	9.2
10"	13	26.3	14	15.6	0.9	8-22 (7/8)	12.4	2.5	11.3
12"	14	29.6	16.3	17.9	1	8-22 (7/8)	14.4	2.5	13.3

Dimensions - Millimeters

Size	L	H	C	D	b	n-d	A	E	B
3"	203	283	157	195	19.1	4-19 (3/4)	126	63.5	104
4"	229	351	191	231	19.1	4-22 (7/8)	153	63.5	125
6"	267	453	241	282	19.1	6-22 (7/8)	207	63.5	178
8"	292	559	299	340	22.2	6-22 (7/8)	261	63.5	233
10"	330	668	356	397	23.8	8-22 (7/8)	314	63.5	285
12"	356	753	413	454	25.4	8-22 (7/8)	367	63.5	338

" "

VK-GT-412MJ

12" Ductile Iron Gate Valve, MJ, NRS, Resilient Wedge, 2" Sq. Nut, AWWA C515

On a standard gate valve with only a metal seal there needs to be a impression for the gate to seat to and make a seal. This impression can get dirt, pebbles, sand or other debris trapped in it, eventually losing its ability to seal 100%. The advantage our resilient seated gate valve has is that the opening in the valve is completely smooth, preventing debris from getting stuck. Even with some impurities the rubber surface will be able to conform and seal.

Features:

• Non-Rising Stem
• Resilient Wedge
• 2" Square Operating Nut
• Fusion Bonded Epoxy Coated Interior and Exterior to AWWA C550 Standard
• Mechanical Joint Connections

Material:

• Body: Ductile Iron
• Bonnet: Ductile Iron
• Wedge: EPDM Covered Ductile Iron
• Stem: Stainless Steel SS420
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	L	H	C	D	b	n-d	A	E	B
3"	8	11.1	6.2	7.7	0.8	4-19 (3/4)	4.9	2.5	4.1
4"	9	13.8	7.5	9.1	0.8	4-22 (7/8)	6	2.5	4.9
6"	10.5	17.8	9.5	11.1	0.8	6-22 (7/8)	8.1	2.5	7
8"	11.5	22	11.8	13.4	0.9	6-22 (7/8)	10.3	2.5	9.2
10"	13	26.3	14	15.6	0.9	8-22 (7/8)	12.4	2.5	11.3
12"	14	29.6	16.3	17.9	1	8-22 (7/8)	14.4	2.5	13.3

Dimensions - Millimeters

Size	L	H	C	D	b	n-d	A	E	B
3"	203	283	157	195	19.1	4-19 (3/4)	126	63.5	104
4"	229	351	191	231	19.1	4-22 (7/8)	153	63.5	125
6"	267	453	241	282	19.1	6-22 (7/8)	207	63.5	178
8"	292	559	299	340	22.2	6-22 (7/8)	261	63.5	233
10"	330	668	356	397	23.8	8-22 (7/8)	314	63.5	285
12"	356	753	413	454	25.4	8-22 (7/8)	367	63.5	338

" "

VK-GT-602

2" Cast Iron Gate Valve - Metal Seated, NRS

Features:

• Suitable for Water, Oil & Steam
• Non-Rising Stem
• Solid Wedge
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Bonnet: Cast Iron
• Wedge: Cast Iron
• Stem: Stainless Steel SS420
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket & Packing: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	n-d	B	Do	H
2"	7	6	4.8	4-19 (3/4")	0.6	7.1	9.4
3"	8	7.5	6	4-19 (3/4")	0.8	7.9	12.7
4"	9	9	7.5	8-19 (3/4")	0.9	10	14.4
6"	10.5	11	9.5	8-22 (7/8")	1	11.8	18.8
8"	11.5	13.5	11.8	8-22 (7/8")	1.1	11.8	23.1
10"	13	16	14.3	12-25 (1")	1.2	13.8	27.9
12"	14	19	17	12-25 (1")	1.3	15.8	31.1

Dimensions - Millimeters

Size	L	D	D1	n-d	B	Do	H
2"	177.8	152	121	4-19 (3/4")	15.9	180	240
3"	203	190	153	4-19 (3/4")	19.1	200	323
4"	229	229	191	8-19 (3/4")	23.9	254	365
6"	267	279	242	8-22 (7/8")	25.4	300	477
8"	292	343	299	8-22 (7/8")	28.6	300	585
10"	330	406	362	12-25 (1")	30.2	350	710
12"	356	483	432	12-25 (1")	31.8	400	789

" "

VK-GT-603

3" Cast Iron Gate Valve - Metal Seated, NRS

Features:

• Suitable for Water, Oil & Steam
• Non-Rising Stem
• Solid Wedge
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Bonnet: Cast Iron
• Wedge: Cast Iron
• Stem: Stainless Steel SS420
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket & Packing: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	n-d	B	Do	H
2"	7	6	4.8	4-19 (3/4")	0.6	7.1	9.4
3"	8	7.5	6	4-19 (3/4")	0.8	7.9	12.7
4"	9	9	7.5	8-19 (3/4")	0.9	10	14.4
6"	10.5	11	9.5	8-22 (7/8")	1	11.8	18.8
8"	11.5	13.5	11.8	8-22 (7/8")	1.1	11.8	23.1
10"	13	16	14.3	12-25 (1")	1.2	13.8	27.9
12"	14	19	17	12-25 (1")	1.3	15.8	31.1

Dimensions - Millimeters

Size	L	D	D1	n-d	B	Do	H
2"	177.8	152	121	4-19 (3/4")	15.9	180	240
3"	203	190	153	4-19 (3/4")	19.1	200	323
4"	229	229	191	8-19 (3/4")	23.9	254	365
6"	267	279	242	8-22 (7/8")	25.4	300	477
8"	292	343	299	8-22 (7/8")	28.6	300	585
10"	330	406	362	12-25 (1")	30.2	350	710
12"	356	483	432	12-25 (1")	31.8	400	789

" "

VK-GT-604

4" Cast Iron Gate Valve - Metal Seated, NRS

Features:

• Suitable for Water, Oil & Steam
• Non-Rising Stem
• Solid Wedge
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Bonnet: Cast Iron
• Wedge: Cast Iron
• Stem: Stainless Steel SS420
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket & Packing: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	n-d	B	Do	H
2"	7	6	4.8	4-19 (3/4")	0.6	7.1	9.4
3"	8	7.5	6	4-19 (3/4")	0.8	7.9	12.7
4"	9	9	7.5	8-19 (3/4")	0.9	10	14.4
6"	10.5	11	9.5	8-22 (7/8")	1	11.8	18.8
8"	11.5	13.5	11.8	8-22 (7/8")	1.1	11.8	23.1
10"	13	16	14.3	12-25 (1")	1.2	13.8	27.9
12"	14	19	17	12-25 (1")	1.3	15.8	31.1

Dimensions - Millimeters

Size	L	D	D1	n-d	B	Do	H
2"	177.8	152	121	4-19 (3/4")	15.9	180	240
3"	203	190	153	4-19 (3/4")	19.1	200	323
4"	229	229	191	8-19 (3/4")	23.9	254	365
6"	267	279	242	8-22 (7/8")	25.4	300	477
8"	292	343	299	8-22 (7/8")	28.6	300	585
10"	330	406	362	12-25 (1")	30.2	350	710
12"	356	483	432	12-25 (1")	31.8	400	789

" "

VK-GT-606

6" Cast Iron Gate Valve - Metal Seated, NRS

Features:

• Suitable for Water, Oil & Steam
• Non-Rising Stem
• Solid Wedge
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Bonnet: Cast Iron
• Wedge: Cast Iron
• Stem: Stainless Steel SS420
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket & Packing: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	n-d	B	Do	H
2"	7	6	4.8	4-19 (3/4")	0.6	7.1	9.4
3"	8	7.5	6	4-19 (3/4")	0.8	7.9	12.7
4"	9	9	7.5	8-19 (3/4")	0.9	10	14.4
6"	10.5	11	9.5	8-22 (7/8")	1	11.8	18.8
8"	11.5	13.5	11.8	8-22 (7/8")	1.1	11.8	23.1
10"	13	16	14.3	12-25 (1")	1.2	13.8	27.9
12"	14	19	17	12-25 (1")	1.3	15.8	31.1

Dimensions - Millimeters

Size	L	D	D1	n-d	B	Do	H
2"	177.8	152	121	4-19 (3/4")	15.9	180	240
3"	203	190	153	4-19 (3/4")	19.1	200	323
4"	229	229	191	8-19 (3/4")	23.9	254	365
6"	267	279	242	8-22 (7/8")	25.4	300	477
8"	292	343	299	8-22 (7/8")	28.6	300	585
10"	330	406	362	12-25 (1")	30.2	350	710
12"	356	483	432	12-25 (1")	31.8	400	789

" "

VK-GT-608

8" Cast Iron Gate Valve - Metal Seated, NRS

Features:

• Suitable for Water, Oil & Steam
• Non-Rising Stem
• Solid Wedge
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Bonnet: Cast Iron
• Wedge: Cast Iron
• Stem: Stainless Steel SS420
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket & Packing: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	n-d	B	Do	H
2"	7	6	4.8	4-19 (3/4")	0.6	7.1	9.4
3"	8	7.5	6	4-19 (3/4")	0.8	7.9	12.7
4"	9	9	7.5	8-19 (3/4")	0.9	10	14.4
6"	10.5	11	9.5	8-22 (7/8")	1	11.8	18.8
8"	11.5	13.5	11.8	8-22 (7/8")	1.1	11.8	23.1
10"	13	16	14.3	12-25 (1")	1.2	13.8	27.9
12"	14	19	17	12-25 (1")	1.3	15.8	31.1

Dimensions - Millimeters

Size	L	D	D1	n-d	B	Do	H
2"	177.8	152	121	4-19 (3/4")	15.9	180	240
3"	203	190	153	4-19 (3/4")	19.1	200	323
4"	229	229	191	8-19 (3/4")	23.9	254	365
6"	267	279	242	8-22 (7/8")	25.4	300	477
8"	292	343	299	8-22 (7/8")	28.6	300	585
10"	330	406	362	12-25 (1")	30.2	350	710
12"	356	483	432	12-25 (1")	31.8	400	789

" "

VK-GT-610

10" Cast Iron Gate Valve - Metal Seated, NRS

Features:

• Suitable for Water, Oil & Steam
• Non-Rising Stem
• Solid Wedge
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Bonnet: Cast Iron
• Wedge: Cast Iron
• Stem: Stainless Steel SS420
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket & Packing: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	n-d	B	Do	H
2"	7	6	4.8	4-19 (3/4")	0.6	7.1	9.4
3"	8	7.5	6	4-19 (3/4")	0.8	7.9	12.7
4"	9	9	7.5	8-19 (3/4")	0.9	10	14.4
6"	10.5	11	9.5	8-22 (7/8")	1	11.8	18.8
8"	11.5	13.5	11.8	8-22 (7/8")	1.1	11.8	23.1
10"	13	16	14.3	12-25 (1")	1.2	13.8	27.9
12"	14	19	17	12-25 (1")	1.3	15.8	31.1

Dimensions - Millimeters

Size	L	D	D1	n-d	B	Do	H
2"	177.8	152	121	4-19 (3/4")	15.9	180	240
3"	203	190	153	4-19 (3/4")	19.1	200	323
4"	229	229	191	8-19 (3/4")	23.9	254	365
6"	267	279	242	8-22 (7/8")	25.4	300	477
8"	292	343	299	8-22 (7/8")	28.6	300	585
10"	330	406	362	12-25 (1")	30.2	350	710
12"	356	483	432	12-25 (1")	31.8	400	789

" "

VK-GT-612

12" Cast Iron Gate Valve - Metal Seated, NRS

Features:

• Suitable for Water, Oil & Steam
• Non-Rising Stem
• Solid Wedge
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Bonnet: Cast Iron
• Wedge: Cast Iron
• Stem: Stainless Steel SS420
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket & Packing: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	n-d	B	Do	H
2"	7	6	4.8	4-19 (3/4")	0.6	7.1	9.4
3"	8	7.5	6	4-19 (3/4")	0.8	7.9	12.7
4"	9	9	7.5	8-19 (3/4")	0.9	10	14.4
6"	10.5	11	9.5	8-22 (7/8")	1	11.8	18.8
8"	11.5	13.5	11.8	8-22 (7/8")	1.1	11.8	23.1
10"	13	16	14.3	12-25 (1")	1.2	13.8	27.9
12"	14	19	17	12-25 (1")	1.3	15.8	31.1

Dimensions - Millimeters

Size	L	D	D1	n-d	B	Do	H
2"	177.8	152	121	4-19 (3/4")	15.9	180	240
3"	203	190	153	4-19 (3/4")	19.1	200	323
4"	229	229	191	8-19 (3/4")	23.9	254	365
6"	267	279	242	8-22 (7/8")	25.4	300	477
8"	292	343	299	8-22 (7/8")	28.6	300	585
10"	330	406	362	12-25 (1")	30.2	350	710
12"	356	483	432	12-25 (1")	31.8	400	789

" "

VK-GT-603-RS

3" Cast Iron Gate Valve - Metal Seated, Rising Stem

Features:

• Suitable for Water, Oil & Steam
• Rising Stem
• Solid Wedge
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Bonnet: Cast Iron
• Wedge: Cast Iron
• Stem: Stainless Steel SS420
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket & Packing: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	n-d	B	Do	H
2"	7	6	4.8	4-19 (3/4")	0.6	7	10.2
3"	8	7.5	6	4-19 (3/4")	0.8	7.9	13.4
4"	9	9	7.5	8-19 (3/4")	0.9	10	16.3
6"	10.5	11	9.5	8-22 (7/8")	1	11	22.1
8"	11.5	13.5	11.8	8-22 (7/8")	1.1	11.8	27.7

Dimensions - Millimeters

Size	L	D	D1	n-d	B	Do	H
2"	178	152	121	4-19 (3/4")	15.9	178	258
3"	203	190	152.5	4-19 (3/4")	19.1	200	341
4"	229	229	190.5	8-19 (3/4")	23.9	254	415
6"	267	279	241.5	8-22 (7/8")	25.4	280	560
8"	292	343	298.5	8-22 (7/8")	28.6	300	703

" "

VK-GT-604-RS

4" Cast Iron Gate Valve - Metal Seated, Rising Stem

Features:

• Suitable for Water, Oil & Steam
• Rising Stem
• Solid Wedge
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Bonnet: Cast Iron
• Wedge: Cast Iron
• Stem: Stainless Steel SS420
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket & Packing: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	n-d	B	Do	H
2"	7	6	4.8	4-19 (3/4")	0.6	7	10.2
3"	8	7.5	6	4-19 (3/4")	0.8	7.9	13.4
4"	9	9	7.5	8-19 (3/4")	0.9	10	16.3
6"	10.5	11	9.5	8-22 (7/8")	1	11	22.1
8"	11.5	13.5	11.8	8-22 (7/8")	1.1	11.8	27.7

Dimensions - Millimeters

Size	L	D	D1	n-d	B	Do	H
2"	178	152	121	4-19 (3/4")	15.9	178	258
3"	203	190	152.5	4-19 (3/4")	19.1	200	341
4"	229	229	190.5	8-19 (3/4")	23.9	254	415
6"	267	279	241.5	8-22 (7/8")	25.4	280	560
8"	292	343	298.5	8-22 (7/8")	28.6	300	703

" "

VK-GT-606-RS

6" Cast Iron Gate Valve - Metal Seated, Rising Stem

Features:

• Suitable for Water, Oil & Steam
• Rising Stem
• Solid Wedge
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Bonnet: Cast Iron
• Wedge: Cast Iron
• Stem: Stainless Steel SS420
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket & Packing: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	n-d	B	Do	H
2"	7	6	4.8	4-19 (3/4")	0.6	7	10.2
3"	8	7.5	6	4-19 (3/4")	0.8	7.9	13.4
4"	9	9	7.5	8-19 (3/4")	0.9	10	16.3
6"	10.5	11	9.5	8-22 (7/8")	1	11	22.1
8"	11.5	13.5	11.8	8-22 (7/8")	1.1	11.8	27.7

Dimensions - Millimeters

Size	L	D	D1	n-d	B	Do	H
2"	178	152	121	4-19 (3/4")	15.9	178	258
3"	203	190	152.5	4-19 (3/4")	19.1	200	341
4"	229	229	190.5	8-19 (3/4")	23.9	254	415
6"	267	279	241.5	8-22 (7/8")	25.4	280	560
8"	292	343	298.5	8-22 (7/8")	28.6	300	703

" "

VK-GT-608-RS

8" Cast Iron Gate Valve - Metal Seated, Rising Stem

Features:

• Suitable for Water, Oil & Steam
• Rising Stem
• Solid Wedge
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Bonnet: Cast Iron
• Wedge: Cast Iron
• Stem: Stainless Steel SS420
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket & Packing: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	n-d	B	Do	H
2"	7	6	4.8	4-19 (3/4")	0.6	7	10.2
3"	8	7.5	6	4-19 (3/4")	0.8	7.9	13.4
4"	9	9	7.5	8-19 (3/4")	0.9	10	16.3
6"	10.5	11	9.5	8-22 (7/8")	1	11	22.1
8"	11.5	13.5	11.8	8-22 (7/8")	1.1	11.8	27.7

Dimensions - Millimeters

Size	L	D	D1	n-d	B	Do	H
2"	178	152	121	4-19 (3/4")	15.9	178	258
3"	203	190	152.5	4-19 (3/4")	19.1	200	341
4"	229	229	190.5	8-19 (3/4")	23.9	254	415
6"	267	279	241.5	8-22 (7/8")	25.4	280	560
8"	292	343	298.5	8-22 (7/8")	28.6	300	703

" "

VK-KG-304

4" Ductile Iron Knife Gate Valve, 2-PC Body, Rising Stem, EPDM Seat

Features:

• Split Body Design
• Rising Stem
• EPDM Seat

Material:

• Body: Ductile Iron
• Stem: Stainless Steel SS420
• Knife: Stainless Steel SS304
• U-Ring: EPDM
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	DN	D	H	L	n-M	W	T
2"	1.9	4.8	13.3	1.9	4-5/8"	7.1	0.5
3"	3.1	6	15.8	2	4-5/8"	7.9	0.6
4"	3.9	7.5	18.4	2	8-5/8"	9.8	0.6
6"	5.9	9.5	24.9	2.3	8-3/4"	11.8	0.7
8"	7.9	11.8	29.3	2.8	8-3/4"	13.8	0.7
10"	9.8	14.3	37	2.8	12-7/8"	15.8	0.7
12"	11.8	17	42.8	3	12-7/8"	19.7	0.7

Dimensions - Millimeters

Size	DN	D	H	L	n-M	W	T
2"	50	120.5	337	48	4-5/8"	180	12.5
3"	80	152.5	400	51	4-5/8"	200	16
4"	100	190.5	466	51	8-5/8"	250	16
6"	150	241.5	633	57	8-3/4"	300	17
8"	200	298.5	744	70	8-3/4"	350	18
10"	250	362	940	70	12-7/8"	400	18
12"	300	432	1087	76	12-7/8"	500	18

" "

VK-KG-306

6" Ductile Iron Knife Gate Valve, 2-PC Body, Rising Stem, EPDM Seat

Features:

• Split Body Design
• Rising Stem
• EPDM Seat

Material:

• Body: Ductile Iron
• Stem: Stainless Steel SS420
• Knife: Stainless Steel SS304
• U-Ring: EPDM
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	DN	D	H	L	n-M	W	T
2"	1.9	4.8	13.3	1.9	4-5/8"	7.1	0.5
3"	3.1	6	15.8	2	4-5/8"	7.9	0.6
4"	3.9	7.5	18.4	2	8-5/8"	9.8	0.6
6"	5.9	9.5	24.9	2.3	8-3/4"	11.8	0.7
8"	7.9	11.8	29.3	2.8	8-3/4"	13.8	0.7
10"	9.8	14.3	37	2.8	12-7/8"	15.8	0.7
12"	11.8	17	42.8	3	12-7/8"	19.7	0.7

Dimensions - Millimeters

Size	DN	D	H	L	n-M	W	T
2"	50	120.5	337	48	4-5/8"	180	12.5
3"	80	152.5	400	51	4-5/8"	200	16
4"	100	190.5	466	51	8-5/8"	250	16
6"	150	241.5	633	57	8-3/4"	300	17
8"	200	298.5	744	70	8-3/4"	350	18
10"	250	362	940	70	12-7/8"	400	18
12"	300	432	1087	76	12-7/8"	500	18

" "

VK-KG-308

8" Ductile Iron Knife Gate Valve, 2-PC Body, Rising Stem, EPDM Seat

Features:

• Split Body Design
• Rising Stem
• EPDM Seat

Material:

• Body: Ductile Iron
• Stem: Stainless Steel SS420
• Knife: Stainless Steel SS304
• U-Ring: EPDM
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	DN	D	H	L	n-M	W	T
2"	1.9	4.8	13.3	1.9	4-5/8"	7.1	0.5
3"	3.1	6	15.8	2	4-5/8"	7.9	0.6
4"	3.9	7.5	18.4	2	8-5/8"	9.8	0.6
6"	5.9	9.5	24.9	2.3	8-3/4"	11.8	0.7
8"	7.9	11.8	29.3	2.8	8-3/4"	13.8	0.7
10"	9.8	14.3	37	2.8	12-7/8"	15.8	0.7
12"	11.8	17	42.8	3	12-7/8"	19.7	0.7

Dimensions - Millimeters

Size	DN	D	H	L	n-M	W	T
2"	50	120.5	337	48	4-5/8"	180	12.5
3"	80	152.5	400	51	4-5/8"	200	16
4"	100	190.5	466	51	8-5/8"	250	16
6"	150	241.5	633	57	8-3/4"	300	17
8"	200	298.5	744	70	8-3/4"	350	18
10"	250	362	940	70	12-7/8"	400	18
12"	300	432	1087	76	12-7/8"	500	18

" "

VK-KG-310

10" Ductile Iron Knife Gate Valve, 2-PC Body, Rising Stem, EPDM Seat

Features:

• Split Body Design
• Rising Stem
• EPDM Seat

Material:

• Body: Ductile Iron
• Stem: Stainless Steel SS420
• Knife: Stainless Steel SS304
• U-Ring: EPDM
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	DN	D	H	L	n-M	W	T
2"	1.9	4.8	13.3	1.9	4-5/8"	7.1	0.5
3"	3.1	6	15.8	2	4-5/8"	7.9	0.6
4"	3.9	7.5	18.4	2	8-5/8"	9.8	0.6
6"	5.9	9.5	24.9	2.3	8-3/4"	11.8	0.7
8"	7.9	11.8	29.3	2.8	8-3/4"	13.8	0.7
10"	9.8	14.3	37	2.8	12-7/8"	15.8	0.7
12"	11.8	17	42.8	3	12-7/8"	19.7	0.7

Dimensions - Millimeters

Size	DN	D	H	L	n-M	W	T
2"	50	120.5	337	48	4-5/8"	180	12.5
3"	80	152.5	400	51	4-5/8"	200	16
4"	100	190.5	466	51	8-5/8"	250	16
6"	150	241.5	633	57	8-3/4"	300	17
8"	200	298.5	744	70	8-3/4"	350	18
10"	250	362	940	70	12-7/8"	400	18
12"	300	432	1087	76	12-7/8"	500	18

" "

VK-KG-312

12" Ductile Iron Knife Gate Valve, 2-PC Body, Rising Stem, EPDM Seat

Features:

• Split Body Design
• Rising Stem
• EPDM Seat

Material:

• Body: Ductile Iron
• Stem: Stainless Steel SS420
• Knife: Stainless Steel SS304
• U-Ring: EPDM
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	DN	D	H	L	n-M	W	T
2"	1.9	4.8	13.3	1.9	4-5/8"	7.1	0.5
3"	3.1	6	15.8	2	4-5/8"	7.9	0.6
4"	3.9	7.5	18.4	2	8-5/8"	9.8	0.6
6"	5.9	9.5	24.9	2.3	8-3/4"	11.8	0.7
8"	7.9	11.8	29.3	2.8	8-3/4"	13.8	0.7
10"	9.8	14.3	37	2.8	12-7/8"	15.8	0.7
12"	11.8	17	42.8	3	12-7/8"	19.7	0.7

Dimensions - Millimeters

Size	DN	D	H	L	n-M	W	T
2"	50	120.5	337	48	4-5/8"	180	12.5
3"	80	152.5	400	51	4-5/8"	200	16
4"	100	190.5	466	51	8-5/8"	250	16
6"	150	241.5	633	57	8-3/4"	300	17
8"	200	298.5	744	70	8-3/4"	350	18
10"	250	362	940	70	12-7/8"	400	18
12"	300	432	1087	76	12-7/8"	500	18

" "

VK-GB-302

2" Cast Iron Globe Valve - Metal Seated

Features:

• Suitable for Water, Oil & Steam
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Bonnet: Cast Iron
• Wedge: Cast Iron
• Stem: Stainless Steel SS420
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	B	n-d	Do	H1	H2
2"	8	6	4.8	0.6	4-19 (3/4")	7	10.1	10.8
3"	9.5	7.5	6	0.8	4-19 (3/4")	7.9	12.7	13.9
4"	11.5	9	7.5	0.9	8-19 (3/4")	10	14.4	15.9
6"	14	11	9.5	1	8-22 (7/8")	11.8	18.6	20.8
8"	19.5	13.5	11.8	1.1	8-22 (7/8")	13.7	21	23.8

Dimensions - Millimeters

Size	L	D	D1	B	n-d	Do	H1	H2
2"	203	152	121	15.9	4-19 (3/4")	178	256	274
3"	241	190	153	19.1	4-19 (3/4")	200	323	353
4"	292	229	191	23.9	8-19 (3/4")	254	365	403
6"	356	279	242	25.4	8-22 (7/8")	300	472	529
8"	495	343	299	28.6	8-22 (7/8")	348	533	605

" "

VK-GB-303

3" Cast Iron Globe Valve - Metal Seated

Features:

• Suitable for Water, Oil & Steam
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Bonnet: Cast Iron
• Wedge: Cast Iron
• Stem: Stainless Steel SS420
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	B	n-d	Do	H1	H2
2"	8	6	4.8	0.6	4-19 (3/4")	7	10.1	10.8
3"	9.5	7.5	6	0.8	4-19 (3/4")	7.9	12.7	13.9
4"	11.5	9	7.5	0.9	8-19 (3/4")	10	14.4	15.9
6"	14	11	9.5	1	8-22 (7/8")	11.8	18.6	20.8
8"	19.5	13.5	11.8	1.1	8-22 (7/8")	13.7	21	23.8

Dimensions - Millimeters

Size	L	D	D1	B	n-d	Do	H1	H2
2"	203	152	121	15.9	4-19 (3/4")	178	256	274
3"	241	190	153	19.1	4-19 (3/4")	200	323	353
4"	292	229	191	23.9	8-19 (3/4")	254	365	403
6"	356	279	242	25.4	8-22 (7/8")	300	472	529
8"	495	343	299	28.6	8-22 (7/8")	348	533	605

" "

VK-GB-304

4" Cast Iron Globe Valve - Metal Seated

Features:

• Suitable for Water, Oil & Steam
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Bonnet: Cast Iron
• Wedge: Cast Iron
• Stem: Stainless Steel SS420
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	B	n-d	Do	H1	H2
2"	8	6	4.8	0.6	4-19 (3/4")	7	10.1	10.8
3"	9.5	7.5	6	0.8	4-19 (3/4")	7.9	12.7	13.9
4"	11.5	9	7.5	0.9	8-19 (3/4")	10	14.4	15.9
6"	14	11	9.5	1	8-22 (7/8")	11.8	18.6	20.8
8"	19.5	13.5	11.8	1.1	8-22 (7/8")	13.7	21	23.8

Dimensions - Millimeters

Size	L	D	D1	B	n-d	Do	H1	H2
2"	203	152	121	15.9	4-19 (3/4")	178	256	274
3"	241	190	153	19.1	4-19 (3/4")	200	323	353
4"	292	229	191	23.9	8-19 (3/4")	254	365	403
6"	356	279	242	25.4	8-22 (7/8")	300	472	529
8"	495	343	299	28.6	8-22 (7/8")	348	533	605

" "

VK-GB-306

6" Cast Iron Globe Valve - Metal Seated

Features:

• Suitable for Water, Oil & Steam
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Bonnet: Cast Iron
• Wedge: Cast Iron
• Stem: Stainless Steel SS420
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	B	n-d	Do	H1	H2
2"	8	6	4.8	0.6	4-19 (3/4")	7	10.1	10.8
3"	9.5	7.5	6	0.8	4-19 (3/4")	7.9	12.7	13.9
4"	11.5	9	7.5	0.9	8-19 (3/4")	10	14.4	15.9
6"	14	11	9.5	1	8-22 (7/8")	11.8	18.6	20.8
8"	19.5	13.5	11.8	1.1	8-22 (7/8")	13.7	21	23.8

Dimensions - Millimeters

Size	L	D	D1	B	n-d	Do	H1	H2
2"	203	152	121	15.9	4-19 (3/4")	178	256	274
3"	241	190	153	19.1	4-19 (3/4")	200	323	353
4"	292	229	191	23.9	8-19 (3/4")	254	365	403
6"	356	279	242	25.4	8-22 (7/8")	300	472	529
8"	495	343	299	28.6	8-22 (7/8")	348	533	605

" "

VK-GB-308

8" Cast Iron Globe Valve - Metal Seated

Features:

• Suitable for Water, Oil & Steam
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Bonnet: Cast Iron
• Wedge: Cast Iron
• Stem: Stainless Steel SS420
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	B	n-d	Do	H1	H2
2"	8	6	4.8	0.6	4-19 (3/4")	7	10.1	10.8
3"	9.5	7.5	6	0.8	4-19 (3/4")	7.9	12.7	13.9
4"	11.5	9	7.5	0.9	8-19 (3/4")	10	14.4	15.9
6"	14	11	9.5	1	8-22 (7/8")	11.8	18.6	20.8
8"	19.5	13.5	11.8	1.1	8-22 (7/8")	13.7	21	23.8

Dimensions - Millimeters

Size	L	D	D1	B	n-d	Do	H1	H2
2"	203	152	121	15.9	4-19 (3/4")	178	256	274
3"	241	190	153	19.1	4-19 (3/4")	200	323	353
4"	292	229	191	23.9	8-19 (3/4")	254	365	403
6"	356	279	242	25.4	8-22 (7/8")	300	472	529
8"	495	343	299	28.6	8-22 (7/8")	348	533	605

" "

VK-YS-302

2" Y Strainer - Ductile Iron, Flanged, SS304 Screen

Features:

• Ductile Iron Body & Cover
• Fusion-Bonded Epoxy Coating Inside & Outside
• Flanges Conform to ANSI B16.1

Material:

• Body: Ductile Iron
• Cover: Ductile Iron
• Screen: Stainless Steel SS304
• Bolts, Nuts & Washers: Stainless Steel SS304 (A2-70)
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	L	D	K	B	n-d	H (±¾")
2"	8.9	6	4.8	0.6	4-19 (3/4")	5.3
3"	11.5	7.5	6	0.8	4-19 (3/4")	6.8
4"	13.9	9	7.5	0.9	8-19 (3/4")	8.1
6"	18.5	11	9.5	1	8-22 (7/8")	11
8"	21.4	13.5	11.8	1.1	8-22 (7/8")	13.8
10"	26	16	14.3	1.2	12-25 (1")	17.2
12"	30	19	17	1.3	12-25 (1")	19.9

Dimensions - Millimeters

Size	DN	L	D	K	B	n-d	H (±20)
2"	50	225	152	120.5	16	4-19 (3/4")	135
3"	80	292	191	152.5	19	4-19 (3/4")	172
4"	100	352	229	190.5	24	8-19 (3/4")	207
6"	150	470	279	241.5	25.5	8-22 (7/8")	279
8"	200	543	343	298.5	29	8-22 (7/8")	350
10"	250	660	406	362	30.5	12-25 (1")	436
12"	300	762	483	432	32	12-25 (1")	506

" "

VK-YS-303

3" Y Strainer - Ductile Iron, Flanged, SS304 Screen

Features:

• Ductile Iron Body & Cover
• Fusion-Bonded Epoxy Coating Inside & Outside
• Flanges Conform to ANSI B16.1

Material:

• Body: Ductile Iron
• Cover: Ductile Iron
• Screen: Stainless Steel SS304
• Bolts, Nuts & Washers: Stainless Steel SS304 (A2-70)
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	L	D	K	B	n-d	H (±¾")
2"	8.9	6	4.8	0.6	4-19 (3/4")	5.3
3"	11.5	7.5	6	0.8	4-19 (3/4")	6.8
4"	13.9	9	7.5	0.9	8-19 (3/4")	8.1
6"	18.5	11	9.5	1	8-22 (7/8")	11
8"	21.4	13.5	11.8	1.1	8-22 (7/8")	13.8
10"	26	16	14.3	1.2	12-25 (1")	17.2
12"	30	19	17	1.3	12-25 (1")	19.9

Dimensions - Millimeters

Size	DN	L	D	K	B	n-d	H (±20)
2"	50	225	152	120.5	16	4-19 (3/4")	135
3"	80	292	191	152.5	19	4-19 (3/4")	172
4"	100	352	229	190.5	24	8-19 (3/4")	207
6"	150	470	279	241.5	25.5	8-22 (7/8")	279
8"	200	543	343	298.5	29	8-22 (7/8")	350
10"	250	660	406	362	30.5	12-25 (1")	436
12"	300	762	483	432	32	12-25 (1")	506

" "

VK-YS-304

4" Y Strainer - Ductile Iron, Flanged, SS304 Screen

Features:

• Ductile Iron Body & Cover
• Fusion-Bonded Epoxy Coating Inside & Outside
• Flanges Conform to ANSI B16.1

Material:

• Body: Ductile Iron
• Cover: Ductile Iron
• Screen: Stainless Steel SS304
• Bolts, Nuts & Washers: Stainless Steel SS304 (A2-70)
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	L	D	K	B	n-d	H (±¾")
2"	8.9	6	4.8	0.6	4-19 (3/4")	5.3
3"	11.5	7.5	6	0.8	4-19 (3/4")	6.8
4"	13.9	9	7.5	0.9	8-19 (3/4")	8.1
6"	18.5	11	9.5	1	8-22 (7/8")	11
8"	21.4	13.5	11.8	1.1	8-22 (7/8")	13.8
10"	26	16	14.3	1.2	12-25 (1")	17.2
12"	30	19	17	1.3	12-25 (1")	19.9

Dimensions - Millimeters

Size	DN	L	D	K	B	n-d	H (±20)
2"	50	225	152	120.5	16	4-19 (3/4")	135
3"	80	292	191	152.5	19	4-19 (3/4")	172
4"	100	352	229	190.5	24	8-19 (3/4")	207
6"	150	470	279	241.5	25.5	8-22 (7/8")	279
8"	200	543	343	298.5	29	8-22 (7/8")	350
10"	250	660	406	362	30.5	12-25 (1")	436
12"	300	762	483	432	32	12-25 (1")	506

" "

VK-YS-306

6" Y Strainer - Ductile Iron, Flanged, SS304 Screen

Features:

• Ductile Iron Body & Cover
• Fusion-Bonded Epoxy Coating Inside & Outside
• Flanges Conform to ANSI B16.1

Material:

• Body: Ductile Iron
• Cover: Ductile Iron
• Screen: Stainless Steel SS304
• Bolts, Nuts & Washers: Stainless Steel SS304 (A2-70)
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	L	D	K	B	n-d	H (±¾")
2"	8.9	6	4.8	0.6	4-19 (3/4")	5.3
3"	11.5	7.5	6	0.8	4-19 (3/4")	6.8
4"	13.9	9	7.5	0.9	8-19 (3/4")	8.1
6"	18.5	11	9.5	1	8-22 (7/8")	11
8"	21.4	13.5	11.8	1.1	8-22 (7/8")	13.8
10"	26	16	14.3	1.2	12-25 (1")	17.2
12"	30	19	17	1.3	12-25 (1")	19.9

Dimensions - Millimeters

Size	DN	L	D	K	B	n-d	H (±20)
2"	50	225	152	120.5	16	4-19 (3/4")	135
3"	80	292	191	152.5	19	4-19 (3/4")	172
4"	100	352	229	190.5	24	8-19 (3/4")	207
6"	150	470	279	241.5	25.5	8-22 (7/8")	279
8"	200	543	343	298.5	29	8-22 (7/8")	350
10"	250	660	406	362	30.5	12-25 (1")	436
12"	300	762	483	432	32	12-25 (1")	506

" "

VK-YS-308

8" Y Strainer - Ductile Iron, Flanged, SS304 Screen

Features:

• Ductile Iron Body & Cover
• Fusion-Bonded Epoxy Coating Inside & Outside
• Flanges Conform to ANSI B16.1

Material:

• Body: Ductile Iron
• Cover: Ductile Iron
• Screen: Stainless Steel SS304
• Bolts, Nuts & Washers: Stainless Steel SS304 (A2-70)
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	L	D	K	B	n-d	H (±¾")
2"	8.9	6	4.8	0.6	4-19 (3/4")	5.3
3"	11.5	7.5	6	0.8	4-19 (3/4")	6.8
4"	13.9	9	7.5	0.9	8-19 (3/4")	8.1
6"	18.5	11	9.5	1	8-22 (7/8")	11
8"	21.4	13.5	11.8	1.1	8-22 (7/8")	13.8
10"	26	16	14.3	1.2	12-25 (1")	17.2
12"	30	19	17	1.3	12-25 (1")	19.9

Dimensions - Millimeters

Size	DN	L	D	K	B	n-d	H (±20)
2"	50	225	152	120.5	16	4-19 (3/4")	135
3"	80	292	191	152.5	19	4-19 (3/4")	172
4"	100	352	229	190.5	24	8-19 (3/4")	207
6"	150	470	279	241.5	25.5	8-22 (7/8")	279
8"	200	543	343	298.5	29	8-22 (7/8")	350
10"	250	660	406	362	30.5	12-25 (1")	436
12"	300	762	483	432	32	12-25 (1")	506

" "

VK-YS-310

10" Y Strainer - Ductile Iron, Flanged, SS304 Screen

Features:

• Ductile Iron Body & Cover
• Fusion-Bonded Epoxy Coating Inside & Outside
• Flanges Conform to ANSI B16.1

Material:

• Body: Ductile Iron
• Cover: Ductile Iron
• Screen: Stainless Steel SS304
• Bolts, Nuts & Washers: Stainless Steel SS304 (A2-70)
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	L	D	K	B	n-d	H (±¾")
2"	8.9	6	4.8	0.6	4-19 (3/4")	5.3
3"	11.5	7.5	6	0.8	4-19 (3/4")	6.8
4"	13.9	9	7.5	0.9	8-19 (3/4")	8.1
6"	18.5	11	9.5	1	8-22 (7/8")	11
8"	21.4	13.5	11.8	1.1	8-22 (7/8")	13.8
10"	26	16	14.3	1.2	12-25 (1")	17.2
12"	30	19	17	1.3	12-25 (1")	19.9

Dimensions - Millimeters

Size	DN	L	D	K	B	n-d	H (±20)
2"	50	225	152	120.5	16	4-19 (3/4")	135
3"	80	292	191	152.5	19	4-19 (3/4")	172
4"	100	352	229	190.5	24	8-19 (3/4")	207
6"	150	470	279	241.5	25.5	8-22 (7/8")	279
8"	200	543	343	298.5	29	8-22 (7/8")	350
10"	250	660	406	362	30.5	12-25 (1")	436
12"	300	762	483	432	32	12-25 (1")	506

" "

VK-YS-312

12" Y Strainer - Ductile Iron, Flanged, SS304 Screen

Features:

• Ductile Iron Body & Cover
• Fusion-Bonded Epoxy Coating Inside & Outside
• Flanges Conform to ANSI B16.1

Material:

• Body: Ductile Iron
• Cover: Ductile Iron
• Screen: Stainless Steel SS304
• Bolts, Nuts & Washers: Stainless Steel SS304 (A2-70)
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	L	D	K	B	n-d	H (±¾")
2"	8.9	6	4.8	0.6	4-19 (3/4")	5.3
3"	11.5	7.5	6	0.8	4-19 (3/4")	6.8
4"	13.9	9	7.5	0.9	8-19 (3/4")	8.1
6"	18.5	11	9.5	1	8-22 (7/8")	11
8"	21.4	13.5	11.8	1.1	8-22 (7/8")	13.8
10"	26	16	14.3	1.2	12-25 (1")	17.2
12"	30	19	17	1.3	12-25 (1")	19.9

Dimensions - Millimeters

Size	DN	L	D	K	B	n-d	H (±20)
2"	50	225	152	120.5	16	4-19 (3/4")	135
3"	80	292	191	152.5	19	4-19 (3/4")	172
4"	100	352	229	190.5	24	8-19 (3/4")	207
6"	150	470	279	241.5	25.5	8-22 (7/8")	279
8"	200	543	343	298.5	29	8-22 (7/8")	350
10"	250	660	406	362	30.5	12-25 (1")	436
12"	300	762	483	432	32	12-25 (1")	506

" "

VK-SWC-303

3" Cast Iron Swing Check Valve - Metal Seated

Features:

• Suitable for Water, Oil & Steam
• Bronze Metal Seated
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Cover: Cast Iron
• Disc: Cast Iron
• Shaft: Stainless Steel SS304
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	B	n-d	H
3"	9.5	7.5	6	0.8	4-19 (3/4")	5.6
4"	11.5	9	7.5	0.9	8-19 (3/4")	6.4
6"	14	11	9.5	1	8-22 (7/8")	8.3
8"	19.5	13.5	11.8	1.1	8-22 (7/8")	10.6

Dimensions - Millimeters

Size	L	D	D1	B	n-d	H
3"	241.3	190	152.5	19	4-19 (3/4")	141
4"	292.1	228.6	190.5	23.8	8-19 (3/4")	162
6"	355.6	279.4	241.3	25.4	8-22 (7/8")	211
8"	495.3	343	298.5	28.6	8-22 (7/8")	270

" "

VK-SWC-304

4" Cast Iron Swing Check Valve - Metal Seated

Features:

• Suitable for Water, Oil & Steam
• Bronze Metal Seated
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Cover: Cast Iron
• Disc: Cast Iron
• Shaft: Stainless Steel SS304
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	B	n-d	H
3"	9.5	7.5	6	0.8	4-19 (3/4")	5.6
4"	11.5	9	7.5	0.9	8-19 (3/4")	6.4
6"	14	11	9.5	1	8-22 (7/8")	8.3
8"	19.5	13.5	11.8	1.1	8-22 (7/8")	10.6

Dimensions - Millimeters

Size	L	D	D1	B	n-d	H
3"	241.3	190	152.5	19	4-19 (3/4")	141
4"	292.1	228.6	190.5	23.8	8-19 (3/4")	162
6"	355.6	279.4	241.3	25.4	8-22 (7/8")	211
8"	495.3	343	298.5	28.6	8-22 (7/8")	270

" "

VK-SWC-306

6" Cast Iron Swing Check Valve - Metal Seated

Features:

• Suitable for Water, Oil & Steam
• Bronze Metal Seated
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Cover: Cast Iron
• Disc: Cast Iron
• Shaft: Stainless Steel SS304
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	B	n-d	H
3"	9.5	7.5	6	0.8	4-19 (3/4")	5.6
4"	11.5	9	7.5	0.9	8-19 (3/4")	6.4
6"	14	11	9.5	1	8-22 (7/8")	8.3
8"	19.5	13.5	11.8	1.1	8-22 (7/8")	10.6

Dimensions - Millimeters

Size	L	D	D1	B	n-d	H
3"	241.3	190	152.5	19	4-19 (3/4")	141
4"	292.1	228.6	190.5	23.8	8-19 (3/4")	162
6"	355.6	279.4	241.3	25.4	8-22 (7/8")	211
8"	495.3	343	298.5	28.6	8-22 (7/8")	270

" "

VK-SWC-308

8" Cast Iron Swing Check Valve - Metal Seated

Features:

• Suitable for Water, Oil & Steam
• Bronze Metal Seated
• Flanges Conform to ANSI B16.1

Material:

• Body: Cast Iron
• Cover: Cast Iron
• Disc: Cast Iron
• Shaft: Stainless Steel SS304
• Body Seat Ring: Bronze B62
• Disc Seat Ring: Bronze B62
• Gasket: Graphite

Download Specification Sheet

Dimensions - Inches

Size	L	D	D1	B	n-d	H
3"	9.5	7.5	6	0.8	4-19 (3/4")	5.6
4"	11.5	9	7.5	0.9	8-19 (3/4")	6.4
6"	14	11	9.5	1	8-22 (7/8")	8.3
8"	19.5	13.5	11.8	1.1	8-22 (7/8")	10.6

Dimensions - Millimeters

Size	L	D	D1	B	n-d	H
3"	241.3	190	152.5	19	4-19 (3/4")	141
4"	292.1	228.6	190.5	23.8	8-19 (3/4")	162
6"	355.6	279.4	241.3	25.4	8-22 (7/8")	211
8"	495.3	343	298.5	28.6	8-22 (7/8")	270

" "

RKCV-2

2" Cast Iron Wafer Check Valve - Double Wing

Features:

• Compact wafer design can be installed in tight spaces
• Can be mounted horizontally or vertically
• Fusion-Bonded Epoxy Coating

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Spring: Stainless Steel AISI 304
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	D	G
2"	4.1	2.6	1.7	2.3	0.8
3"	5.4	3.7	2.5	3.4	3
4"	6.9	4.6	2.5	4.3	3.8
6"	8.8	6.7	3	6.7	5.7
8"	11	8.8	3.5	8.8	7.6
10"	13.4	10.4	4.5	10.4	9.4
12"	16.1	12.2	4.5	12.2	10.2

Dimensions - Millimeters

Size	A	B	C	D	G
2"	105	65	43	59	20
3"	137	94	64	88	76
4"	175	117	64	110	97
6"	222	170	76	170	145
8"	279	224	89	222	193
10"	340	265	114	264	239
12"	410	310	114	310	259

" "

RKCV-3

3" Cast Iron Wafer Check Valve - Double Wing

Features:

• Compact wafer design can be installed in tight spaces
• Can be mounted horizontally or vertically
• Fusion-Bonded Epoxy Coating

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Spring: Stainless Steel AISI 304
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	D	G
2"	4.1	2.6	1.7	2.3	0.8
3"	5.4	3.7	2.5	3.4	3
4"	6.9	4.6	2.5	4.3	3.8
6"	8.8	6.7	3	6.7	5.7
8"	11	8.8	3.5	8.8	7.6
10"	13.4	10.4	4.5	10.4	9.4
12"	16.1	12.2	4.5	12.2	10.2

Dimensions - Millimeters

Size	A	B	C	D	G
2"	105	65	43	59	20
3"	137	94	64	88	76
4"	175	117	64	110	97
6"	222	170	76	170	145
8"	279	224	89	222	193
10"	340	265	114	264	239
12"	410	310	114	310	259

" "

RKCV-4

4" Cast Iron Wafer Check Valve - Double Wing

Features:

• Compact wafer design can be installed in tight spaces
• Can be mounted horizontally or vertically
• Fusion-Bonded Epoxy Coating

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Spring: Stainless Steel AISI 304
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	D	G
2"	4.1	2.6	1.7	2.3	0.8
3"	5.4	3.7	2.5	3.4	3
4"	6.9	4.6	2.5	4.3	3.8
6"	8.8	6.7	3	6.7	5.7
8"	11	8.8	3.5	8.8	7.6
10"	13.4	10.4	4.5	10.4	9.4
12"	16.1	12.2	4.5	12.2	10.2

Dimensions - Millimeters

Size	A	B	C	D	G
2"	105	65	43	59	20
3"	137	94	64	88	76
4"	175	117	64	110	97
6"	222	170	76	170	145
8"	279	224	89	222	193
10"	340	265	114	264	239
12"	410	310	114	310	259

" "

RKCV-6

6" Cast Iron Wafer Check Valve - Double Wing

Features:

• Compact wafer design can be installed in tight spaces
• Can be mounted horizontally or vertically
• Fusion-Bonded Epoxy Coating

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Spring: Stainless Steel AISI 304
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	D	G
2"	4.1	2.6	1.7	2.3	0.8
3"	5.4	3.7	2.5	3.4	3
4"	6.9	4.6	2.5	4.3	3.8
6"	8.8	6.7	3	6.7	5.7
8"	11	8.8	3.5	8.8	7.6
10"	13.4	10.4	4.5	10.4	9.4
12"	16.1	12.2	4.5	12.2	10.2

Dimensions - Millimeters

Size	A	B	C	D	G
2"	105	65	43	59	20
3"	137	94	64	88	76
4"	175	117	64	110	97
6"	222	170	76	170	145
8"	279	224	89	222	193
10"	340	265	114	264	239
12"	410	310	114	310	259

" "

RKCV-8

8" Cast Iron Wafer Check Valve - Double Wing

Features:

• Compact wafer design can be installed in tight spaces
• Can be mounted horizontally or vertically
• Fusion-Bonded Epoxy Coating

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Spring: Stainless Steel AISI 304
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	D	G
2"	4.1	2.6	1.7	2.3	0.8
3"	5.4	3.7	2.5	3.4	3
4"	6.9	4.6	2.5	4.3	3.8
6"	8.8	6.7	3	6.7	5.7
8"	11	8.8	3.5	8.8	7.6
10"	13.4	10.4	4.5	10.4	9.4
12"	16.1	12.2	4.5	12.2	10.2

Dimensions - Millimeters

Size	A	B	C	D	G
2"	105	65	43	59	20
3"	137	94	64	88	76
4"	175	117	64	110	97
6"	222	170	76	170	145
8"	279	224	89	222	193
10"	340	265	114	264	239
12"	410	310	114	310	259

" "

RKCV-10

10" Cast Iron Wafer Check Valve - Double Wing

Features:

• Compact wafer design can be installed in tight spaces
• Can be mounted horizontally or vertically
• Fusion-Bonded Epoxy Coating

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Spring: Stainless Steel AISI 304
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	D	G
2"	4.1	2.6	1.7	2.3	0.8
3"	5.4	3.7	2.5	3.4	3
4"	6.9	4.6	2.5	4.3	3.8
6"	8.8	6.7	3	6.7	5.7
8"	11	8.8	3.5	8.8	7.6
10"	13.4	10.4	4.5	10.4	9.4
12"	16.1	12.2	4.5	12.2	10.2

Dimensions - Millimeters

Size	A	B	C	D	G
2"	105	65	43	59	20
3"	137	94	64	88	76
4"	175	117	64	110	97
6"	222	170	76	170	145
8"	279	224	89	222	193
10"	340	265	114	264	239
12"	410	310	114	310	259

" "

RKCV-12

12" Cast Iron Wafer Check Valve - Double Wing

Features:

• Compact wafer design can be installed in tight spaces
• Can be mounted horizontally or vertically
• Fusion-Bonded Epoxy Coating

Material:

• Body: Cast Iron
• Disc: Nickel Plated Ductile Iron
• Seat: EPDM
• Stem: Stainless Steel SS416
• Spring: Stainless Steel AISI 304
• Paint: Fusion-Bonded Epoxy

Download Specification Sheet

Dimensions - Inches

Size	A	B	C	D	G
2"	4.1	2.6	1.7	2.3	0.8
3"	5.4	3.7	2.5	3.4	3
4"	6.9	4.6	2.5	4.3	3.8
6"	8.8	6.7	3	6.7	5.7
8"	11	8.8	3.5	8.8	7.6
10"	13.4	10.4	4.5	10.4	9.4
12"	16.1	12.2	4.5	12.2	10.2

Dimensions - Millimeters

Size	A	B	C	D	G
2"	105	65	43	59	20
3"	137	94	64	88	76
4"	175	117	64	110	97
6"	222	170	76	170	145
8"	279	224	89	222	193
10"	340	265	114	264	239
12"	410	310	114	310	259

" "

RKP-2

2" Pressure Relief Valve 22-80 PSI w/Small Spring & Orange Encasing

Features:

• Aluminum cover with 1-1/2" FNPT drain port
• Adjustable pressure setting
• Cover with orange color powder coating for easy visibility and longer life

To set the pressure, first remove the nut holding on the orange cover. Underneath the cover you will see two more nuts that apply pressure to the spring. Loosening the nuts will reduce the pressure cracking point. The relief valve comes preset at 60PSI."

RKP-3

3" Pressure Relief Valve 22-80 PSI - Internal Spring (preset @ 80 PSI)

Features:

• Provides pressure surge protection for irrigation systems
• Adjustable pressure setting maximizes performance for individual applications
• High-strength cast aluminum body and stainless steel shaft offer strength and corrosion resistance

RKPR-2

2" Pressure Relief Valve 22-120 PSI - Big External Spring (preset @ 80 PSI)

Features:

• Provides pressure surge protection for irrigation systems
• Adjustable pressure setting maximizes performance for individual applications
• High-strength cast aluminum body and stainless steel shaft offer strength and corrosion resistance

Material:

• Body: Aluminum
• Spring: Galvanized Steel

RKPR-3

3" Pressure Relief Valve 22-120 PSI - Big External Spring (preset @ 80 PSI)

Features:

• Provides pressure surge protection for irrigation systems
• Adjustable pressure setting maximizes performance for individual applications
• High-strength cast aluminum body and stainless steel shaft offer strength and corrosion resistance

Material:

• Body: Aluminum
• Spring: Galvanized Steel

RKARV-100

1" Simple Action Aluminum Air Release/Vacuum Relief Vent

Features:

• Simple design ensures trouble-free performance
• Cast aluminum body combines the dual advantage of being lightweight as well as provides corrosion resistance
• Synthetic rubber seal assures positive rubber seal, even with low head applications

Material:

• Body: Aluminum

Features:

• Simple design ensures trouble-free performance
• Cast aluminum body combines the dual advantage of being lightweight as well as provides corrosion resistance
• Synthetic rubber seal assures positive rubber seal, even with low head applications

Material:

• Body: Aluminum

Features:

• Simple design ensures trouble-free performance
• Cast aluminum body combines the dual advantage of being lightweight as well as provides corrosion resistance
• Synthetic rubber seal assures positive rubber seal, even with low head applications

Material:

• Body: Aluminum

Features:

• Simple design ensures trouble-free performance
• Cast aluminum body combines the dual advantage of being lightweight as well as provides corrosion resistance
• Synthetic rubber seal assures positive rubber seal, even with low head applications

Material:

• Body: Aluminum
• Paint: Epoxy
• Paint: Epoxy

Features:

• Simple design ensures trouble-free performance
• Cast aluminum body combines the dual advantage of being lightweight as well as provides corrosion resistance
• Synthetic rubber seal assures positive rubber seal, even with low head applications

Material:

• Body: Aluminum

Features:

• Simple design ensures trouble-free performance
• Cast aluminum body combines the dual advantage of being lightweight as well as provides corrosion resistance
• Synthetic rubber seal assures positive rubber seal, even with low head applications

Material:

• Body: Aluminum

RKARVC-200

2" Aluminum Air Release, Vacuum Relief, Continuous Air Vent

Features:

• Provides continuous air release during system operation
• Exhausts large volume of trapped air from pipeline
• Promotes full line capacity and provides vacuum protection
• Max Pressure: 150 PSI

Material:

• Body: Aluminum

" "

RKARVC-300

3" Aluminum Air Release, Vacuum Relief, Continuous Air Vent

Features:

• Provides continuous air release during system operation
• Exhausts large volume of trapped air from pipeline
• Promotes full line capacity and provides vacuum protection
• Max Pressure: 100 PSI

Material:

• Body: Aluminum

"

RKAV75

3/4" Simple Action Plastic Air Release/Vacuum Relief Vent

Features:

• Durable, weather resistant and non-corrosive
• Made of reinforced polypropylene & polyamide (nylon)
• Seals at 5 PSI

Material:

• Body: Plastic

RKAV100

1" Simple Action Plastic Air Release/Vacuum Relief Vent

Features:

• Durable, weather resistant and non-corrosive
• Made of reinforced polypropylene & polyamide (nylon)
• Seals at 5 PSI

Material:

• Body: Plastic

RKAV200

2" Simple Action Plastic Air Release/Vacuum Relief Vent

Features:

• Durable, weather resistant and non-corrosive
• Made of reinforced polypropylene & polyamide (nylon)
• Seals at 5 PSI

Material:

• Body: Plastic

RKAV300

3" Simple Action Plastic Air Release/Vacuum Relief Vent

Features:

• Durable, weather resistant and non-corrosive
• Made of reinforced polypropylene & polyamide (nylon)
• Seals at 5 PSI

Material:

• Body: Plastic

"

RKAVC100

1" Plastic Air Release, Vacuum Relief, Continuous Air Vent

Features:

• Manufactured out of durable, weather resistant and non-corrosive reinforced polyamide (nylon)
• Minimum sealing pressure at 5 PSI
• Threaded elbow outlet

Material:

• Body: Plastic

" "

RKAVC200

2" Plastic Air Release, Vacuum Relief, Continuous Air Vent

Features:

• Manufactured out of durable, weather resistant and non-corrosive reinforced polyamide (nylon)
• Threaded elbow outlet

Material:

• Body: Plastic

"

VK-EXT-24-2-3

24" Stem Extension for 2" & 3" Butterfly Valves

VK-EXT-24-4

24" Stem Extension for 4" Butterfly Valves

VK-EXT-24-6

24" Stem Extension for 6" Butterfly Valves

VK-EXT-24-8

24" Stem Extension for 8" Butterfly Valves

VK-EXT-24-10

24" Stem Extension for 10" Butterfly Valves

VK-EXT-24-12

24" Stem Extension for 12" Butterfly Valves

VK-EXT-36-2-3

36" Stem Extension for 2" & 3" Butterfly Valves

VK-EXT-36-4

36" Stem Extension for 4" Butterfly Valves

VK-EXT-36-6

36" Stem Extension for 6" Butterfly Valves

VK-EXT-36-8

36" Stem Extension for 8" Butterfly Valves

VK-EXT-36-10

36" Stem Extension for 10" Butterfly Valves

VK-EXT-36-12

36" Stem Extension for 12" Butterfly Valves

VK-EXT-48-2-3

48" Stem Extension for 2" & 3" Butterfly Valves

VK-EXT-48-4

48" Stem Extension for 4" Butterfly Valves

VK-EXT-48-6

48" Stem Extension for 6" Butterfly Valves

VK-EXT-48-8

48" Stem Extension for 8" Butterfly Valves

VK-EXT-48-10

48" Stem Extension for 10" Butterfly Valves

VK-EXT-48-12

48" Stem Extension for 12" Butterfly Valves

VK-EXT-60-2-3

60" Stem Extension for 2" & 3" Butterfly Valves

VK-EXT-60-4

60" Stem Extension for 4" Butterfly Valves

VK-EXT-60-6

60" Stem Extension for 6" Butterfly Valves

VK-EXT-60-8

60" Stem Extension for 8" Butterfly Valves

VK-EXT-60-10

60" Stem Extension for 10" Butterfly Valves

VK-EXT-60-12

60" Stem Extension for 12" Butterfly Valves

VK-SQN-2

2" Square Operating Nut for 2" Resilient Wedge Gate Valves

VK-SQN-3-4

2" Square Operating Nut for 3" & 4" Resilient Wedge Gate Valves

VK-SQN-6

2" Square Operating Nut for 6" Resilient Wedge Gate Valves

VK-SQN-8-14

2" Square Operating Nut for 8" to 14" Resilient Wedge Gate Valves

VK-HW-2

Hand Wheel for 2" NRS Resilient Wedge Gate Valves

VK-HW-3-4

Hand Wheel for 3" & 4" NRS Resilient Wedge Gate Valves

VK-HW-6

Hand Wheel for 6" NRS Resilient Wedge Gate Valves

VK-HW-8-10

Hand Wheel for 8" to 10" NRS Resilient Wedge Gate Valves

VK-HW-12-14

Hand Wheel for 12" to 14" NRS Resilient Wedge Gate Valves

VK-HW-3-4RS

Hand Wheel for 3" & 4" Rising Stem Resilient Wedge Gate Valves

VK-HW-6RS

Hand Wheel for 6" Rising Stem Resilient Wedge Gate Valves

VK-HW-8-10RS

Hand Wheel for 8" to 10" Rising Stem Resilient Wedge Gate Valves

RKBV3O-ORING

RKBV3O (T) Union O-Ring
