6" Cast Iron Gate Valve - Metal Seated, NRS
was
$1,660.67
Special Price
$1,206.25
Cast iron gate valve with cast bronze seat and non-rising stem.
| Size | 6" |
|---|---|
| Design Standard | MSS SP-70 |
| Stem | Non-Rising Stem |
| Operator | Handwheel |
| Connections | Flanged / ANSI 125 |
| Length (End to End) | 10.5" |
| Weight | 144 lbs |
Availability:
In stock
SKU
VK-GT-606
6" Cast Iron Gate Valve - Metal Seated, NRS
Compatible with square nut adapter VK-SQN-6
Features:
- Suitable for Water, Oil & Steam
- Non-Rising Stem
- Solid Wedge
- Flanges Conform to ANSI B16.1
Material:
- Body: Cast Iron
- Bonnet: Cast Iron
- Wedge: Cast Iron
- Stem: Stainless Steel SS420
- Body Seat Ring: Bronze B62
- Disc Seat Ring: Bronze B62
- Gasket & Packing: Graphite
Download Specification Sheet
Dimensions - Inches
| Size | L | D | D1 | n-d | B | Do | H |
|---|---|---|---|---|---|---|---|
| 2" | 7 | 6 | 4.8 | 4-19 (3/4") | 0.6 | 7.1 | 9.4 |
| 3" | 8 | 7.5 | 6 | 4-19 (3/4") | 0.8 | 7.9 | 12.7 |
| 4" | 9 | 9 | 7.5 | 8-19 (3/4") | 0.9 | 10 | 14.4 |
| 6" | 10.5 | 11 | 9.5 | 8-22 (7/8") | 1 | 11.8 | 18.8 |
| 8" | 11.5 | 13.5 | 11.8 | 8-22 (7/8") | 1.1 | 11.8 | 23.1 |
| 10" | 13 | 16 | 14.3 | 12-25 (1") | 1.2 | 13.8 | 27.9 |
| 12" | 14 | 19 | 17 | 12-25 (1") | 1.3 | 15.8 | 31.1 |
Dimensions - Millimeters
| Size | L | D | D1 | n-d | B | Do | H |
|---|---|---|---|---|---|---|---|
| 2" | 177.8 | 152 | 121 | 4-19 (3/4") | 15.9 | 180 | 240 |
| 3" | 203 | 190 | 153 | 4-19 (3/4") | 19.1 | 200 | 323 |
| 4" | 229 | 229 | 191 | 8-19 (3/4") | 23.9 | 254 | 365 |
| 6" | 267 | 279 | 242 | 8-22 (7/8") | 25.4 | 300 | 477 |
| 8" | 292 | 343 | 299 | 8-22 (7/8") | 28.6 | 300 | 585 |
| 10" | 330 | 406 | 362 | 12-25 (1") | 30.2 | 350 | 710 |
| 12" | 356 | 483 | 432 | 12-25 (1") | 31.8 | 400 | 789 |
